17-300680

Active

Amphenol CONEC

CONN COUPLER RCPT LC-LC DUPLEX

Search across all available documentation for this part.

Active

Amphenol CONEC

CONN COUPLER RCPT LC-LC DUPLEX

Technical Specifications

Parameters and characteristics for this part

Specification	17-300680

Color	Silver
Convert From (Adapter End)	LC Receptacle
Convert To (Adapter End)	LC Receptacle
Features	Mounting Hardware, Dust Cap
Housing Material	Zinc Die Cast
Ingress Protection	IP67 - Dust Tight, Waterproof
Material Flammability Rating	UL94 V-0
Mode	Multimode
Mounting Type	Panel Mount, Flange
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Simplex/Duplex	Duplex
Type	Coupler

Part	Type	Simplex/Duplex	Housing Material	Operating Temperature [Max]	Operating Temperature [Min]	Ferrule Material	Mounting Type	Color	Ingress Protection	Features	Convert From (Adapter End)	Convert To (Adapter End)	Mode	Material Flammability Rating
Amphenol CONEC 17-300670	Coupler	Duplex	Zinc Die Cast	85 °C	-40 °C	Ceramic	Flange Panel Mount	Silver	IP67 - Dust Tight Waterproof	Dust Cap Mounting Hardware	LC Receptacle	LC Receptacle	Singlemode	UL94 V-0
Amphenol CONEC 17-300680	Coupler	Duplex	Zinc Die Cast	85 °C	-40 °C		Flange Panel Mount	Silver	IP67 - Dust Tight Waterproof	Dust Cap Mounting Hardware	LC Receptacle	LC Receptacle	Multimode	UL94 V-0
Amphenol CONEC 17-300690	Coupler	Duplex	Zinc Die Cast	85 °C	-40 °C	Ceramic	Flange Panel Mount	Silver	IP67 - Dust Tight Waterproof		LC Receptacle	LC Receptacle	Singlemode	UL94 V-0

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Coupler Fiber Optic Connector LC Receptacle To LC Receptacle Panel Mount, Flange
