HD60125G

Active

Sensata-Crydom

SSR RELAY SPST-NO 125A 48-660V

Search across all available documentation for this part.

Active

Sensata-Crydom

SSR RELAY SPST-NO 125A 48-660V

Technical Specifications

Parameters and characteristics for this part

Part	Mounting Type	Voltage - Load [Min]	Voltage - Load [Max]	Load Current	Operating Temperature [Min]	Operating Temperature [Max]	Output Type	Voltage - Input [Max]	Voltage - Input [Min]	Termination Style	Package / Case	Approval Agency
Sensata-Crydom HD60125	Chassis Mount	48 V	660 V	125 A	-40 °C	80 C	AC Zero Cross	32 V	3 V	Screw Terminal	Hockey Puck	CE CSA cURus TUV
Sensata-Crydom HD60125K-10	Chassis Mount	48 V	660 V	125 A	-40 °C	80 C	AC	32 V	3 V	Screw Terminal	Hockey Puck	CE CSA cURus TUV
Sensata-Crydom HD60125G	Chassis Mount	48 V	660 V	125 A	-40 °C	80 C	AC Zero Cross	32 V	4 V	Screw Terminal	Hockey Puck	CE CSA cURus TUV
Sensata-Crydom HD60125-10	Chassis Mount	48 V	660 V	125 A	-40 °C	80 C	AC	32 V	3 V	Screw Terminal	Hockey Puck	CE CSA cURus TUV

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	10	$ 141.44

General part information

Solid State SPST-NO (1 Form A) Hockey Puck

Technical documentation and resources
