1415356-1
ActiveTE Connectivity Potter & Brumfield Relays
PBH34036
Deep-Dive with AI
Search across all available documentation for this part.
1415356-1
ActiveTE Connectivity Potter & Brumfield Relays
PBH34036
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 1415356-1 |
|---|---|
| Approval Agency | cURus, VDE |
| Coil Current | 10 mA |
| Coil Resistance | 3.6 kOhms |
| Coil Type | Non Latching |
| Coil Voltage | 36 VDC |
| Contact Form | SPST-NO (1 Form A) |
| Contact Material | Silver Nickel (AgNi) |
| Contact Rating (Current) | 6 A |
| Load - Max Switching [Max] | 2400 VA |
| Mounting Type | Through Hole |
| Operate Time | 10 ms |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | -20 C |
| Relay Type | General Purpose |
| Release Time | 20 ms |
| Switching Voltage [Max] | 400 VAC |
| Termination Style | PC Pin |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 1050 | $ 2.70 | |
Description
General part information
PBH340 Series
General Purpose Relay SPST-NO (1 Form A) 36VDC Coil Through Hole
Documents
Technical documentation and resources
No documents available
