EP-6-11P

Active

AMPHENOL AUDIO

CONN PLUG FMALE 6P TIN SLDR CUP

Search across all available documentation for this part.

Active

AMPHENOL AUDIO

CONN PLUG FMALE 6P TIN SLDR CUP

Technical Specifications

Parameters and characteristics for this part

Specification	EP-6-11P

Applications	Audio
Cable Opening [Max] [diameter]	16 mm
Cable Opening [Max] [diameter]	0.63 in
Cable Opening [Min] [diameter]	0.354 in
Cable Opening [Min] [diameter]	9 mm
Color	Silver
Connector Type	Female Sockets, Plug
Contact Material	Brass
Current Rating (Amps)	20 A
Fastening Type	Latch Lock
Features	Cable Clamp, Backshell
Ingress Protection	IP40
Insert Material	Polybutylene Terephthalate (PBT)
Material Flammability Rating	UL94 V-0
Mounting Type	Free Hanging (In-Line)
Number of Positions	6
Operating Temperature [Max]	75 ░C
Operating Temperature [Min]	-25 °C
Orientation	Keyed
Primary Material	Metal
Shell Finish	Nickel
Shell Material	Zinc Die Cast
Shielding	Unshielded

CONN PLUG FMALE 6P TIN SLDR CUP

Part	Color	Cable Opening [Max] [diameter]	Cable Opening [Min] [diameter]	Cable Opening [Max] [diameter]	Cable Opening [Min] [diameter]	Shielding	Contact Material	Connector Type	Number of Positions	Insert Material	Shell Material	Features	Ingress Protection	Applications	Current Rating (Amps)	Mounting Type	Operating Temperature [Min]	Operating Temperature [Max]	Primary Material	Material Flammability Rating	Orientation	Fastening Type	Shell Finish
AMPHENOL AUDIO EP-6-11P	Silver	16 mm	0.354 in	0.63 in	9 mm	Unshielded	Brass	Female Sockets, Plug	6	Polybutylene Terephthalate (PBT)	Zinc Die Cast	Backshell, Cable Clamp	IP40	Audio	20 A	Free Hanging (In-Line)	-25 °C	75 ░C	Metal	UL94 V-0	Keyed	Latch Lock	Nickel

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

6 Position Circular Connector Plug, Female Sockets Solder Cup
