Specification	CCM01-2013AP LFT T30

Card Type	Smart Card
Connector Type	Connector
Contact Finish	Gold
Features	Board Guide, Switch
Height Above Board	0.244 in
Insertion, Removal Method	Push In, Pull Out
Mounting Feature	Top, Normal, Standard
Mounting Type	Right Angle, Surface Mount
Number of Positions	10

CCM01 Series

Full Size Card - Low Profile Smart Card Reader

Part	Features	Connector Type	Contact Finish	Mounting Type	Number of Positions	Mounting Feature	Insertion, Removal Method	Card Type	Height Above Board
LITTELFUSE CCM01-2013AP LFT T30	Board Guide Switch	Connector	Gold	Right Angle Surface Mount	10	Normal Standard Top	Pull Out Push In	Smart Card	0.244 in
LITTELFUSE CCM01-2634 LFT T25	Board Guide Switch	Connector		Right Angle Surface Mount	10	Normal Standard Top	Pull Out Push In	Smart Card	0.126 in
LITTELFUSE CCM012112LFTT30	Board Guide Switch	Connector	Gold	Right Angle Through Hole	10	Normal Standard Top	Pull Out Push In	Smart Card	0.244 in
LITTELFUSE CCM01-2565LFT T25	Shielded Switch	Connector		Right Angle Surface Mount	10	Normal Standard Top	Pull Out Push In	Smart Card	0.157 in
LITTELFUSE CCM01-1NF	Board Lock Switch	Connector	Gold	Right Angle Through Hole	10	Normal Standard Top	Pull Out Push In	Smart Card	0.256 in
LITTELFUSE CCM01-2251LFT T30	Board Guide Switch	Connector	Gold	Right Angle Surface Mount	10	Normal Standard Top	Pull Out Push In	Smart Card	0.248 in
LITTELFUSE CCM01-2633 LFT T25	Board Guide Shielded Switch	Connector		Right Angle Surface Mount	10	Normal Standard Top	Pull Out Push In	Smart Card	0.126 in
LITTELFUSE CCM01-2663 LFT T25	Board Guide Shielded Switch	Connector		Right Angle Surface Mount	10	Normal Standard Top	Pull Out Push In	Smart Card	0.126 in
LITTELFUSE CCM01-2553LFT T25	Shielded Switch	Connector		Right Angle Surface Mount	10	Normal Standard Top	Pull Out Push In	Smart Card	0.157 in
LITTELFUSE CCM012027LFTT25	Board Guide Switch	Connector	Gold	Right Angle Surface Mount	10	Normal Standard Top	Pull Out Push In	Smart Card	0.23 in
