BB4502NS

Active

TE Connectivity Raychem Cable Protection

2DBI SPRING ANTENNA VERTICAL 460MHZ ANTENNAS ROHS

Search across all available documentation for this part.

Active

TE Connectivity Raychem Cable Protection

2DBI SPRING ANTENNA VERTICAL 460MHZ ANTENNAS ROHS

Technical Specifications

Parameters and characteristics for this part

Part	Frequency Range [Min]	Frequency Range [Max]	Height (Max) [Max] [z]	Height (Max)	Gain	VSWR	Antenna Type	Number of Bands	Mounting Type	Frequency Group [Max]	Frequency Group [Min]	Frequency (Center/Band)	Termination
TE Connectivity Raychem Cable Protection BB4502N-L	450 MHz	470 MHz	12.5 in	317.5 mm	2.4 dBi	2	Whip Straight	1	Base Mount	1 GHz	300 MHz	460 MHz	NMO
TE Connectivity Raychem Cable Protection BB4502NS	450 MHz	470 MHz	12.5 in	317.5 mm	2.4 dBi	2	Whip Straight	1	Base Mount	1 GHz	300 MHz	460 MHz	NMO

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

RF ANTENNA Whip, Straight NMO Base Mount

Technical documentation and resources

No documents available
