PSK-45-15-T
CUI Inc.
AC/DC CONVERTER 15V 45W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
PSK-45-15-T
CUI Inc.
AC/DC CONVERTER 15V 45W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | PSK-45-15-T |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | CE, cURus |
| Current - Output 1 | 3 A |
| Efficiency | 85 % |
| Features | Universal Input |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Size / Dimension [x] | 135 mm |
| Size / Dimension [x] | 5.32 in |
| Size / Dimension [y] | 70 mm |
| Size / Dimension [y] | 2.76 in |
| Size / Dimension [z] | 37.9 mm |
| Size / Dimension [z] | 1.49 in |
| Standard Number | 62368-1 |
| Type | Enclosed |
| Voltage - Input [Max] | 264 VAC, 370 VDC |
| Voltage - Input [Min] | 100 V, 85 VAC |
| Voltage - Isolation | 4000 V |
| Voltage - Output 1 | 15 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 1 | $ 20.99 | |
| 8 | $ 19.70 | |||
Description
General part information
PSK-45 Series
Enclosed AC DC Converters 1 Output 15V 85 ~ 264 VAC, 100 ~ 370 VDC Input
