A069R
ActiveTPI (Test Products Int)
CROC CLIP INSULATED 5MA
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
A069R
ActiveTPI (Test Products Int)
CROC CLIP INSULATED 5MA
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | A069R | A069 Series |
|---|---|---|
| Color | Red | Black, Red |
| Current Rating (Amps) | 5 mA | 5 mA |
| Insulation | Insulated | Insulated |
| Jaw Opening | 0.79 in | 0.79 in |
| Jaw Opening | 20.07 mm | 20.07 mm |
| Length [x] | 6.18 " | 6.18 " |
| Length [x] | 156.97 mm | 156.97 mm |
| Quantity | 1 Box | 1 Box |
| Ratings | CAT III | CAT III |
| Ratings | 1000 V | 1000 V |
| Termination | Banana, Female Socket (Jack) | Banana, Female Socket (Jack) |
| Type | Crocodile, Safety | Crocodile, Safety |
| Voltage - Rated | 1 kV | 1 kV |
| Voltage - Rated | 1000 V | 1000 V |
A069 Series
CROC CLIP INSULATED 5MA
| Part | Length [x] | Length [x] | Jaw Opening | Jaw Opening | Termination | Type | Insulation | Voltage - Rated | Voltage - Rated | Color | Quantity | Current Rating (Amps) | Ratings | Ratings |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TPI (Test Products Int) A069B | 6.18 " | 156.97 mm | 0.79 in | 20.07 mm | Banana, Female Socket (Jack) | Crocodile, Safety | Insulated | 1 kV | 1000 V | Black | 1 Box | 5 mA | CAT III | 1000 V |
TPI (Test Products Int) A069R | 6.18 " | 156.97 mm | 0.79 in | 20.07 mm | Banana, Female Socket (Jack) | Crocodile, Safety | Insulated | 1 kV | 1000 V | Red | 1 Box | 5 mA | CAT III | 1000 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 50 | $ 10.85 | |
Description
General part information
A069 Series
5 mA Insulated Crocodile, Safety Test Clip 0.790" (20.07mm) 1000V (1kV)
