EN3L4FX

Active

Switchcraft Inc.

CONN RCPT FMALE 4P GOLD SLDR CUP

Search across all available documentation for this part.

Active

Switchcraft Inc.

CONN RCPT FMALE 4P GOLD SLDR CUP

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	EN3L4FX	EN3L4F Series

Applications	Instrumentation, Medical, General Purpose, Marine	Instrumentation, Medical, General Purpose, Marine
Backshell Material, Plating	Thermoplastic	Thermoplastic
Cable Opening [diameter]	6.73 mm, 4.06 mm	4.06 - 6.73 mm
Cable Opening [diameter]	0.265 in, 0.16 in	0.16 - 0.265 in
Color	Black	Black
Connector Type	Receptacle, Female Sockets	Receptacle, Female Sockets
Contact Finish - Mating	Gold	Gold
Contact Material	Copper Alloy	Copper Alloy
Current Rating (Amps)	7.5 A	7.5 A
Fastening Type	Bayonet Lock	Bayonet Lock
Features	Cable Clamp, Backshell	Cable Clamp, Backshell
Ingress Protection	IP66/IP68	IP66/IP68
Insert Material	Elastomer	Elastomer
Material Flammability Rating	UL94 V-0	UL94 V-0
Mounting Type	Free Hanging (In-Line)	Free Hanging (In-Line)
Number of Positions	4	4
Operating Temperature [Max]	65 °C	65 °C
Operating Temperature [Min]	-40 °C	-40 °C
Orientation	Keyed	Keyed
Primary Material	Plastic	Plastic
Shielding	Unshielded	Unshielded
Voltage Rating	250 VAC	250 VAC

CONN RCPT FMALE 4P GOLD SLDR CUP

Part	Applications	Primary Material	Cable Opening [diameter]	Cable Opening [diameter]	Orientation	Ingress Protection	Number of Positions	Contact Material	Operating Temperature [Max]	Operating Temperature [Min]	Connector Type	Voltage Rating	Contact Finish - Mating	Features	Color	Shielding	Insert Material	Material Flammability Rating	Backshell Material, Plating	Mounting Type	Current Rating (Amps)	Fastening Type
Switchcraft Inc. EN3L4FX	General Purpose, Instrumentation, Marine, Medical	Plastic	4.06 mm, 6.73 mm	0.16 in, 0.265 in	Keyed	IP66/IP68	4	Copper Alloy	65 °C	-40 °C	Receptacle, Female Sockets	250 VAC	Gold	Backshell, Cable Clamp	Black	Unshielded	Elastomer	UL94 V-0	Thermoplastic	Free Hanging (In-Line)	7.5 A	Bayonet Lock
Switchcraft Inc. EN3L4FKX	General Purpose, Instrumentation, Marine, Medical	Plastic	4.06 mm, 6.73 mm	0.16 in, 0.265 in	Keyed	IP66/IP68	4	Copper Alloy	65 °C	-40 °C	Receptacle, Female Sockets	250 VAC	Gold	Backshell, Cable Clamp	Black	Unshielded	Elastomer	UL94 V-0	Thermoplastic	Free Hanging (In-Line)	7.5 A	Bayonet Lock

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

4 Position Circular Connector Receptacle, Female Sockets Solder Cup
