FN406-6-02

Active

TE Connectivity Raychem Cable Protection

LINE FILTER 250VAC 6A TH

Search across all available documentation for this part.

Active

TE Connectivity Raychem Cable Protection

LINE FILTER 250VAC 6A TH

Technical Specifications

Parameters and characteristics for this part

Specification	FN406-6-02

Applications	General Purpose
Approval Agency	CSA, ENEC, UR
Configuration	Single Stage
Current	6 A
Filter Type	Single Phase
Frequency - Operating	400 Hz
Inductance	780 µH
Mounting Type	Through Hole
Operating Temperature [custom]	100 °C, -25 °C
Termination Style	PC Pins
Voltage - Rated AC	250 V

Part	Applications	Current	Inductance	Mounting Type	Configuration	Filter Type	Voltage - Rated AC	Operating Temperature [custom]	Termination Style	Approval Agency	Frequency - Operating
TE Connectivity Raychem Cable Protection FN406B-0.5-02	General Purpose	500 mA	24 mH	Through Hole	Single Stage	Single Phase	250 V	-25 °C 100 °C	PC Pins	CSA ENEC UR	400 Hz
TE Connectivity Raychem Cable Protection FN406-6-02	General Purpose	6 A	780 µH	Through Hole	Single Stage	Single Phase	250 V	-25 °C 100 °C	PC Pins	CSA ENEC UR	400 Hz
TE Connectivity Raychem Cable Protection FN406B-8.4-02	General Purpose	8.4 A	300 µH	Through Hole	Single Stage	Single Phase	250 V	-25 °C 100 °C	PC Pins	CSA ENEC UR	400 Hz
TE Connectivity Raychem Cable Protection FN406-1-02	General Purpose	1 A	12 mH	Through Hole	Single Stage	Single Phase	250 V	-25 °C 100 °C	PC Pins	CSA ENEC UR	400 Hz
TE Connectivity Raychem Cable Protection FN406B-1-02	General Purpose	1 A	12 mH	Through Hole	Single Stage	Single Phase	250 V	-25 °C 100 °C	PC Pins	CSA ENEC UR	400 Hz

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Single Phase EMC/EMI Line Filter 6 A 250V DC ~ 400Hz Single Stage PC Pins
