TCSD-18-01-N

Active

Samtec Inc.

CONN RCPT 36POS IDC 28AWG GOLD

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

TCSD-18-01-N

Active

Samtec Inc.

CONN RCPT 36POS IDC 28AWG GOLD

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	TCSD-18-01-N

Cable Termination	IDC
Color	Black
Connector Type	Receptacle
Contact Finish	Gold
Contact Finish Thickness	0.76 Ám
Contact Finish Thickness	30 Áin
Contact Type	Female Socket
Fastening Type	Push-Pull
Features	Polarizing Key, Feed Through
Mounting Type	Free Hanging (In-Line)
Number of Positions	36
Number of Rows	2
Pitch [x]	0.079 in
Pitch [x]	2 mm
Row Spacing	2 mm
Row Spacing	0.079 in
Wire Gauge	28 AWG
Wire Type	Ribbon Cable

TCSD-18 Series

Part	Contact Finish Thickness	Contact Finish Thickness	Length [x]	Length [x]	Length [x]	Pitch - Cable	Pitch - Cable [custom]	Number of Positions	Pitch - Connector	Pitch - Connector	Cable Termination	Features	Connector Type	Contact Finish	Number of Rows	Shielding	Length	Length	Length	Contact Finish Thickness	Mounting Type	Contact Type	Row Spacing	Row Spacing	Wire Type	Fastening Type	Pitch [x]	Pitch [x]	Wire Gauge	Color
Samtec Inc. TCSD-18-D-04.00-01-N	0.76 Ám	30 Áin	4 "	0.333 ft	101.6 mm	1 mm	0.039 "	36	2 mm	0.079 in	IDC	Polarizing Key	Socket to Socket	Gold	2	Unshielded
Samtec Inc. TCSD-18-S-40.00-01	0.76 Ám	30 Áin		3.33 '	1.02 m	1 mm	0.039 "	36	2 mm	0.079 in	IDC		Socket to Cable	Gold	2	Unshielded
Samtec Inc. TCSD-18-D-04.00-01	0.76 Ám	30 Áin	4 "	0.333 ft	101.6 mm	1 mm	0.039 "	36	2 mm	0.079 in	IDC		Socket to Socket	Gold	2	Unshielded
Samtec Inc. TCSD-18-D-08.00-01-N	0.76 Ám	30 Áin				1 mm	0.039 "	36	2 mm	0.079 in	IDC	Polarizing Key	Socket to Socket	Gold	2	Unshielded	0.667 ft	8 in	203.2 mm
Samtec Inc. TCSD-18-D-12.00-01-F-R						1 mm	0.039 "	36	2 mm	0.079 in	IDC		Socket to Socket Reversed	Gold	2	Unshielded	1 ft		304.8 mm	Flash
Samtec Inc. TCSD-18-D-12.00-01-N-RW-R	0.76 Ám	30 Áin				1 mm	0.039 "	36	2 mm	0.079 in	IDC	Polarizing Key Reverse Wiring	Socket to Socket Reversed	Gold	2	Unshielded	1 ft		304.8 mm
Samtec Inc. TCSD-18-D-12.00-01-F-N						1 mm	0.039 "	36	2 mm	0.079 in	IDC	Polarizing Key	Socket to Socket	Gold	2	Unshielded	1 ft		304.8 mm	Flash
Samtec Inc. TCSD-18-D-02.50-01-N	0.76 Ám	30 Áin	2.5 in	2.496 in	63.5 mm	1 mm	0.039 "	36	2 mm	0.079 in	IDC	Polarizing Key	Socket to Socket	Gold	2	Unshielded
Samtec Inc. TCSD-18-D-10.00-01-N-R	0.76 Ám	30 Áin				1 mm	0.039 "	36	2 mm	0.079 in	IDC	Polarizing Key	Socket to Socket Reversed	Gold	2	Unshielded	0.833 ft	10 in	254 mm
Samtec Inc. TCSD-18-01-N	0.76 Ám	30 Áin						36			IDC	Feed Through Polarizing Key	Receptacle	Gold	2						Free Hanging (In-Line)	Female Socket	2 mm	0.079 in	Ribbon Cable	Push-Pull	0.079 in	2 mm	28 AWG	Black

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tube	14	$ 8.48

Description

General part information

TCSD-18 Series

36 Position Rectangular Receptacle Connector IDC Gold 28 AWG
