Q-2L07400132.5M

Active

Amphenol Custom Cable

CBL ASSY NTYPE-TNC PLUG-PLG 8.2'

Deep-Dive with AI

Search across all available documentation for this part.

Q-2L07400132.5M

Active

Amphenol Custom Cable

CBL ASSY NTYPE-TNC PLUG-PLG 8.2'

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	Q-2L07400132.5M

1st Connector Mounting Type	Free Hanging (In-Line)
1st Contact Gender	Male
2nd Connector	TNC Plug
2nd Connector Mounting Type	Free Hanging (In-Line)
2nd Contact Gender	Male
Cable Type	LMR 400
Color	Black
Features	Shielded
Frequency - Max [Max]	6000 MHz
Length	8.2 '
Length	98.4 in
Length	2.5 m
Overall Impedance	50 Ohms

Q-2L0740 Series

Part	Cable Type	1st Contact Gender	Frequency - Max [Max]	Overall Impedance	2nd Connector	Features	2nd Connector Mounting Type	1st Connector Mounting Type	Length [x]	Length [x]	2nd Contact Gender	Color	Length	Length	Length [x]	Length
Amphenol Custom Cable Q-2L0740013018i	LMR 400	Male	6000 MHz	50 Ohms	TNC Plug	Shielded	Free Hanging (In-Line)	Free Hanging (In-Line)	457.2 mm	457.2 mm	Male	Black
Amphenol Custom Cable Q-2L0740013009i	LMR 400	Male	6000 MHz	50 Ohms	TNC Plug	Shielded	Free Hanging (In-Line)	Free Hanging (In-Line)			Male	Black	9 "	228.6 mm
Amphenol Custom Cable Q-2L0740013012i	LMR 400	Male	6000 MHz	50 Ohms	TNC Plug	Shielded	Free Hanging (In-Line)	Free Hanging (In-Line)			Male	Black	12 "	304.8 mm
Amphenol Custom Cable Q-2L0740013.25M	LMR 400	Male	6000 MHz	50 Ohms	TNC Plug	Shielded	Free Hanging (In-Line)	Free Hanging (In-Line)		250 mm	Male	Black			9.843 "
Amphenol Custom Cable Q-2L0740013060i	LMR 400	Male	6000 MHz	50 Ohms	TNC Plug	Shielded	Free Hanging (In-Line)	Free Hanging (In-Line)			Male	Black	5 '	1.5 m		5 ft
Amphenol Custom Cable Q-2L0740013006i	LMR 400	Male	6000 MHz	50 Ohms	TNC Plug	Shielded	Free Hanging (In-Line)	Free Hanging (In-Line)			Male	Black	6 in	152.4 mm
Amphenol Custom Cable Q-2L0740013003i	LMR 400	Male	6000 MHz	50 Ohms	TNC Plug	Shielded	Free Hanging (In-Line)	Free Hanging (In-Line)			Male	Black	3 in	76.2 mm
Amphenol Custom Cable Q-2L0740013024i	LMR 400	Male	6000 MHz	50 Ohms	TNC Plug	Shielded	Free Hanging (In-Line)	Free Hanging (In-Line)			Male	Black	24 "	609.6 mm
Amphenol Custom Cable Q-2L07400132.5M	LMR 400	Male	6000 MHz	50 Ohms	TNC Plug	Shielded	Free Hanging (In-Line)	Free Hanging (In-Line)			Male	Black	98.4 in	2.5 m		8.2 '
Amphenol Custom Cable Q-2L0740013108i	LMR 400	Male	6000 MHz	50 Ohms	TNC Plug	Shielded	Free Hanging (In-Line)	Free Hanging (In-Line)			Male	Black	108 in	2.7 m		9 ft

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bag	1	$ 122.92
		25	$ 114.56
		50	$ 106.21
		100	$ 99.05
		250	$ 93.09

Description

General part information

Q-2L0740 Series

Cable Assembly Coaxial N-Type to TNC LMR 400 98.4" (2.5m) 8.2'

Documents

Technical documentation and resources

No documents available
