MGM240LA22VIF2
ActiveSilicon Labs
MULTIPROTOCOL MODULE 256KB RAM
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MGM240LA22VIF2
ActiveSilicon Labs
MULTIPROTOCOL MODULE 256KB RAM
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | MGM240LA22VIF2 |
|---|---|
| Antenna Type | PCB Trace |
| Current - Receiving [Max] | 7.7 mA |
| Current - Receiving [Min] | 6.6 mA |
| Current - Transmitting [Max] | 29.8 mA |
| Current - Transmitting [Min] | 7.4 mA |
| Data Rate | 2 Mbps |
| Frequency | 2.4 GHz |
| Memory Size | 256 kB, 1.5 MB |
| Modulation | O-QPSK, DSSS, GFSK |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Module |
| Power - Output | 10 dBm |
| Protocol | Thread, Zigbee®, Bluetooth v5.3 |
| RF Family/Standard | Bluetooth, 802.15.4 |
| Sensitivity | -95.4 dBm |
| Serial Interfaces | SPI, USART, GPIO, I2C, ADC, I2S, IrDA, UART, PWM |
| Utilized IC / Part | EFR32MG24 |
| Voltage - Supply [Max] | 3.8 V |
| Voltage - Supply [Min] | 1.8 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Strip | 1 | $ 13.07 | |
| 10 | $ 11.82 | |||
| 25 | $ 10.89 | |||
| 100 | $ 9.95 | |||
| 250 | $ 9.33 | |||
| 500 | $ 8.71 | |||
| 1000 | $ 8.27 | |||
Description
General part information
MGM240L Series
802.15.4, Bluetooth Bluetooth v5.3, Thread, Zigbee® Transceiver Module 2.4GHz PCB Trace Surface Mount
