H11AA4X

Active

Isocom Components 2004 LTD

OPTOISO 5.3KV TRANS W/BASE 6DIP

Search across all available documentation for this part.

Active

Isocom Components 2004 LTD

OPTOISO 5.3KV TRANS W/BASE 6DIP

Technical Specifications

Parameters and characteristics for this part

Specification	H11AA4X

Current - DC Forward (If) (Max)	50 mA
Current - Output / Channel	50 mA
Current Transfer Ratio (Min) [Min]	100 %
Mounting Type	Through Hole
Number of Channels	1
Operating Temperature [Max]	100 °C
Operating Temperature [Min]	-30 ░C
Package / Case	6-DIP
Package / Case	0.3 in
Package / Case	7.62 mm
Rise / Fall Time (Typ) [custom]	3 µs
Rise / Fall Time (Typ) [custom]	4 µs
Supplier Device Package	6-DIP
Vce Saturation (Max) [Max]	400 mV
Voltage - Isolation	5300 Vrms
Voltage - Output (Max) [Max]	35 V

OPTOISO 5.3KV TRANS W/BASE 6DIP

Part	Current Transfer Ratio (Min) [Min]	Vce Saturation (Max) [Max]	Current - Output / Channel	Number of Channels	Mounting Type	Rise / Fall Time (Typ) [custom]	Rise / Fall Time (Typ) [custom]	Voltage - Output (Max) [Max]	Package / Case	Package / Case	Package / Case	Voltage - Isolation	Operating Temperature [Max]	Operating Temperature [Min]	Current - DC Forward (If) (Max)	Supplier Device Package
Isocom Components 2004 LTD H11AA4X	100 %	400 mV	50 mA	1	Through Hole	3 µs	4 µs	35 V	6-DIP	0.3 in	7.62 mm	5300 Vrms	100 °C	-30 ░C	50 mA	6-DIP

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Optoisolator Transistor with Base Output 5300Vrms 1 Channel 6-DIP
