DBS150A24
ObsoleteCosel USA, Inc.
DC DC CONVERTER 24V 151W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
DBS150A24
ObsoleteCosel USA, Inc.
DC DC CONVERTER 24V 151W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | DBS150A24 |
|---|---|
| Applications | ITE (Commercial) |
| Current - Output (Max) [Max] | 6.3 A |
| Efficiency | 87 % |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Package / Case | 21-DIP Module |
| Power (Watts) | 151 W |
| Size / Dimension [x] | 4.6 " |
| Size / Dimension [x] | 116.8 mm |
| Size / Dimension [y] | 2.4 " |
| Size / Dimension [y] | 61 mm |
| Size / Dimension [z] | 0.5 in |
| Size / Dimension [z] | 12.7 mm |
| Type | Isolated Module |
| Voltage - Input (Max) [Max] | 160 V |
| Voltage - Input (Min) [Min] | 66 V |
| Voltage - Output 1 | 24 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 148.18 | |
Description
General part information
DBS150 Series
Isolated Module DC DC Converter 1 Output 24V 6.3A 66V - 160V Input
