8777 0603280

Active

Belden Inc.

MULTI-PAIR 6COND 22AWG

Search across all available documentation for this part.

Active

Belden Inc.

MULTI-PAIR 6COND 22AWG

Technical Specifications

Parameters and characteristics for this part

Specification	8777 0603280

Cable Type	Multi-Pair
Conductor Insulation	Polypropylene (PP)
Conductor Material	Copper, Tinned
Conductor Strand [custom]	7
Conductor Strand [custom]	30 AWG
Features	Drain Wire
Jacket (Insulation) Diameter [diameter]	0.273 in
Jacket (Insulation) Diameter [diameter]	6.93 mm
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)
Jacket (Insulation) Thickness	0.864 mm
Jacket (Insulation) Thickness	0.034 in
Jacket Color	Chrome
Length	3281 ft
Length	1000 m
Number of Conductors	6
Operating Temperature [Max]	80 C
Operating Temperature [Min]	-20 C
Ratings	UL Style 2919
Shield Coverage	100 %
Shield Material	Aluminum
Shield Type	Foil
Wire Gauge	22 AWG

Part	Length [x]	Length [x]	Cable Type	Conductor Material	Shield Coverage	Conductor Strand [custom]	Conductor Strand [custom]	Jacket Color	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Operating Temperature [Min]	Operating Temperature [Max]	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Shield Material	Features	Number of Conductors	Wire Gauge	Jacket (Insulation) Material	Conductor Insulation	Shield Type	Length	Length	Ratings
Belden Inc. 8777 060100	30.5 m	100 ft	Multi-Pair	Copper Tinned	100 %	7	30 AWG	Chrome	0.864 mm	0.034 in	-20 C	80 C	0.273 in	6.93 mm	Aluminum Polyester	Drain Wire	6	22 AWG	Poly-Vinyl Chloride (PVC)	Polypropylene (PP)	Foil
Belden Inc. 8777 0603280			Multi-Pair	Copper Tinned	100 %	7	30 AWG	Chrome	0.864 mm	0.034 in	-20 C	80 C	0.273 in	6.93 mm	Aluminum	Drain Wire	6	22 AWG	Poly-Vinyl Chloride (PVC)	Polypropylene (PP)	Foil	3281 ft	1000 m	UL Style 2919
Belden Inc. 8777 060250			Multi-Pair	Copper Tinned	100 %	7	30 AWG	Chrome	0.864 mm	0.034 in	-20 C	80 C	0.273 in	6.93 mm	Aluminum	Drain Wire	6	22 AWG	Poly-Vinyl Chloride (PVC)	Polypropylene (PP)	Foil	3000 "	76.2 m	UL Style 2919

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	1000	$ 8.36

General part information

6 (3 Pair Twisted) Conductor Multi-Pair Cable Chrome 22 AWG Foil 3281' (1000.0m)
