AA07S1500A

Obsolete

Delta Electronics

AC/DC CONVERTER 15V 7W

Search across all available documentation for this part.

Obsolete

Delta Electronics

AC/DC CONVERTER 15V 7W

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Enclosed AC DC Converters 1 Output 15V 466mA 85 ~ 264 VAC Input

Technical documentation and resources

Parameters and characteristics commom to parts in this series

AC/DC CONVERTER 3.3V 7W

Part	Mounting Type	Power (Watts)	Features	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [x]	Line Regulation	Weight	Weight	Efficiency	Number of Outputs	Current - Output (Max) [Max]	Package / Case	Voltage - Output 1	Type	Applications	Standard Number	Load Regulation	Operating Temperature [Min]	Operating Temperature [Max]	Approval Agency
Delta Electronics AA07S0300A	Through Hole	7 W	Universal Input	25.4 mm	19.5 mm	25.4 mm	0.77 "	50.8 mm	2 in	0.5 %	44 g	0.097 lb	70 %	1	1.4 A	4-DIP Module	3.3 V	Enclosed	ITE (Commercial)	60950-1	0.5 %	-25 °C	70 °C	CE, UL
Delta Electronics AA07S1500A	Through Hole	7 W	Universal Input	25.4 mm	19.5 mm	25.4 mm	0.77 "	50.8 mm	2 in	0.5 %	44 g	0.097 lb	78 %	1	466 mA	4-DIP Module	15 V	Enclosed	ITE (Commercial)	60950-1	0.5 %	-25 °C	70 °C	CE, UL
