MC07XSF517EK

Active

Freescale Semiconductor

HIGH-SIDE SWITCH, 18V, TRIPLE 7M

Search across all available documentation for this part.

Active

Freescale Semiconductor

HIGH-SIDE SWITCH, 18V, TRIPLE 7M

Technical Specifications

Parameters and characteristics for this part

Specification	MC07XSF517EK

Current - Output (Max) [Max]	11 A
Current - Output (Max) [Min]	5.5 A
Fault Protection	Open Load Detect, Current Limiting (Fixed), Over Temperature
Features	Internal PWM
Input Type	CMOS
Interface	SPI
Mounting Type	Surface Mount
Number of Outputs	6
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-40 °C
Output Configuration	High Side
Output Type	N-Channel
Package / Case	0.295 in
Package / Case	7.5 mm
Package / Case	54-SSOP
Ratio - Input:Output [custom]	1:1
Rds On (Typ)	17 mOhm, 7 mOhm
Supplier Device Package	54-HSOP
Switch Type	General Purpose
Voltage - Load [Max]	18 V
Voltage - Load [Min]	7 V
Voltage - Supply (Vcc/Vdd) [Max]	5.5 V
Voltage - Supply (Vcc/Vdd) [Min]	4.5 V

HIGH-SIDE SWITCH, 18V, TRIPLE 7M

Part	Rds On (Typ)	Output Type	Interface	Operating Temperature [Min]	Operating Temperature [Max]	Supplier Device Package	Current - Output (Max) [Min]	Current - Output (Max) [Max]	Fault Protection	Switch Type	Input Type	Voltage - Supply (Vcc/Vdd) [Max]	Voltage - Supply (Vcc/Vdd) [Min]	Voltage - Load [Max]	Voltage - Load [Min]	Package / Case	Package / Case	Package / Case	Ratio - Input:Output [custom]	Features	Number of Outputs	Mounting Type	Output Configuration
Freescale Semiconductor MC07XSF517EK	7 mOhm, 17 mOhm	N-Channel	SPI	-40 °C	125 °C	54-HSOP	5.5 A	11 A	Current Limiting (Fixed), Open Load Detect, Over Temperature	General Purpose	CMOS	5.5 V	4.5 V	18 V	7 V	0.295 in	7.5 mm	54-SSOP	1:1	Internal PWM	6	Surface Mount	High Side

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	50	$ 6.07

General part information

Power Switch/Driver 1:1 N-Channel 5.5A, 11A 54-HSOP
