53QK501-272N5

Obsolete

Rosenberger

N TYPE BULKHEAD JACK

Search across all available documentation for this part.

Obsolete

Rosenberger

N TYPE BULKHEAD JACK

Technical Specifications

Parameters and characteristics for this part

Specification	53QK501-272N5

Body Finish	White Bronze
Body Material	Brass
Center Contact Material	Bronze
Center Contact Plating	Gold
Connector Style	N Type
Connector Type	Female Socket, Jack
Contact Termination	Solder Cup
Dielectric Material	Polytetrafluoroethylene (PTFE)
Frequency - Max [Max]	11 GHz
Housing Color	Silver
Impedance	50 Ohms
Mating Cycles	200
Mounting Feature	Bulkhead - Front Side Nut
Number of Ports	1
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-40 °C
Shield Termination	Solder
Voltage Rating	500 V

Part	Operating Temperature [Max]	Operating Temperature [Min]	Center Contact Material	Connector Type	Body Material	Contact Termination	Impedance	Body Finish	Housing Color	Shield Termination	Number of Ports	Frequency - Max [Max]	Voltage Rating	Mating Cycles	Center Contact Plating	Mounting Feature	Connector Style	Dielectric Material
Rosenberger 53QK501-272N5	125 °C	-40 °C	Bronze	Female Socket Jack	Brass	Solder Cup	50 Ohms	White Bronze	Silver	Solder	1	11 GHz	500 V	200	Gold	Bulkhead - Front Side Nut	N Type	Polytetrafluoroethylene (PTFE)

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

N Type Connector Jack, Female Socket 50 Ohms Panel Mount Solder Cup
