General part information
Pluggable Terminal Blocks 13 Pos 5mm pitch Plug 24-16AWG Spring
Technical documentation and resources
Parameters and characteristics commom to parts in this series
| Specification | 1732797 | FKCN Series |
|---|---|---|
| Color | Green | Green |
| Contact Mating Finish | Tin | Tin |
| Current - IEC | 12 A | 12 A |
| Current - UL | - | 10 A |
| Features | - | Retention Latches (Non-Wire Side), Mating Flange |
| Housing Material | Polybutylene Terephthalate (PBT) | Polybutylene Terephthalate (PBT), Polyamide (PA), Nylon |
| Insulation Height | 0.429 in | 0.429 in |
| Insulation Height | 10.9 mm | 10.9 mm |
| Material Flammability Rating | UL94 V-0 | UL94 V-0 |
| Mounting Type | Free Hanging (In-Line) | Free Hanging (In-Line) |
| Number of Levels | 1 | 1 |
| Number of Positions | 7 | 4 - 18 |
| Pitch [x] | 5 mm | 5 - 5.08 mm |
| Pitch [x] | 0.197 in | 0.197 - 0.2 in |
| Positions Per Level | 7 | 4 - 18 |
| Termination Style | Screwless - Push-In Spring | Screwless - Push-In Spring, Push-In Spring, Screwless - Leg Spring |
| Type | Plug, Female Sockets | Plug, Female Sockets |
| Voltage - IEC | 630 V | 630 V |
| Voltage - UL | - | 300 V |
| Wire Gauge or Range - AWG [Max] | 24 AWG | 24 AWG |
| Wire Gauge or Range - AWG [Min] | 16 AWG | 14 - 16 AWG |
| Wire Gauge or Range - mm˛ | - | 0.2 mm˛ |
| Wire Gauge or Range - mm˛ | - | 1.5 mm˛ |
| Wire Gauge or Range - mm² [Max] | 1.5 mm² | 1.5 mm² |
| Wire Gauge or Range - mm² [Min] | 0.2 mm² | 0.2 mm² |
| Wire Strip Length | 10 mm | 10 mm |
Pluggable Terminal Blocks 13 Pos 5mm pitch Plug 24-16AWG Spring
| Part | Mounting Type | Current - IEC | Type | Wire Gauge or Range - AWG [Max] | Wire Gauge or Range - AWG [Min] | Positions Per Level | Color | Wire Gauge or Range - mm˛ [Min] | Wire Gauge or Range - mm˛ [Max] | Wire Strip Length | Housing Material | Material Flammability Rating | Contact Mating Finish | Voltage - IEC | Insulation Height | Insulation Height | Number of Levels | Termination Style | Pitch [x] | Pitch [x] | Number of Positions | Voltage - UL | Wire Gauge or Range - mm² [Min] | Wire Gauge or Range - mm² [Max] | Current - UL | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Phoenix Contact 1732894 | Free Hanging (In-Line) | 12 A | Plug, Female Sockets | 24 AWG | 16 AWG | 18 | Green | 0.2 mm˛ | 1.5 mm˛ | 10 mm | Polybutylene Terephthalate (PBT) | UL94 V-0 | Tin | 630 V | 0.429 in | 10.9 mm | 1 | Screwless - Push-In Spring | 5 mm | 0.197 in | 18 | |||||
Phoenix Contact 1754681 | Free Hanging (In-Line) | 12 A | Plug, Female Sockets | 24 AWG | 14 AWG | 14 | Green | 10 mm | Polyamide (PA), Nylon | UL94 V-0 | Tin | 630 V | 0.429 in | 10.9 mm | 1 | Push-In Spring, Screwless - Leg Spring | 5.08 mm | 0.2 in | 14 | 300 V | 0.2 mm² | 1.5 mm² | 10 A | |||
Phoenix Contact 1732797 | Free Hanging (In-Line) | 12 A | Plug, Female Sockets | 24 AWG | 16 AWG | 7 | Green | 10 mm | Polybutylene Terephthalate (PBT) | UL94 V-0 | Tin | 630 V | 0.429 in | 10.9 mm | 1 | Screwless - Push-In Spring | 5 mm | 0.197 in | 7 | 0.2 mm² | 1.5 mm² | |||||
Phoenix Contact 1733068 | Free Hanging (In-Line) | 12 A | Plug, Female Sockets | 24 AWG | 16 AWG | 13 | Green | 0.2 mm˛ | 1.5 mm˛ | 10 mm | Polybutylene Terephthalate (PBT) | UL94 V-0 | Tin | 630 V | 0.429 in | 10.9 mm | 1 | Screwless - Push-In Spring | 5 mm | 0.197 in | 13 | Mating Flange, Retention Latches (Non-Wire Side) | ||||
Phoenix Contact 1732988 | Free Hanging (In-Line) | 12 A | Plug, Female Sockets | 24 AWG | 16 AWG | 4 | Green | 0.2 mm˛ | 1.5 mm˛ | 10 mm | Polybutylene Terephthalate (PBT) | UL94 V-0 | Tin | 630 V | 0.429 in | 10.9 mm | 1 | Screwless - Push-In Spring | 5 mm | 0.197 in | 4 | Mating Flange, Retention Latches (Non-Wire Side) |
