ZUW152412-G

Active

Cosel USA, Inc.

DC DC CONVERTER +/-12V 24V 16W

Search across all available documentation for this part.

Active

Cosel USA, Inc.

DC DC CONVERTER +/-12V 24V 16W

Technical Specifications

Parameters and characteristics for this part

DC DC CONVERTER +/-12V 24V 16W

Part	Voltage - Input (Min) [Min]	Power (Watts)	Voltage - Input (Max) [Max]	Voltage - Output 2	Efficiency	Voltage - Output 1	Type	Current - Output (Max)	Current - Output (Max)	Number of Outputs	Mounting Type	Applications	Operating Temperature [Min]	Operating Temperature [Max]	Package / Case	Voltage - Isolation	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]
Cosel USA, Inc. ZUW152412-G	18 V	16 W	36 V	-12 V	83 %	12 V	Isolated Module	650 mA	650 mA	2	Through Hole	ITE (Commercial)	-20 °C	71 °C	7-DIP Module	500 V	0.33 in	1.97 "	1.77 "	50 mm	8.5 mm	45 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 71.44

General part information

Isolated Module DC DC Converter 2 Output 12V -12V 650mA, 650mA 18V - 36V Input
