AXT424124A

Active

Panasonic Electric Works

CONN HDR 24POS SMD GOLD

Search across all available documentation for this part.

Active

Panasonic Electric Works

CONN HDR 24POS SMD GOLD

Technical Specifications

Parameters and characteristics for this part

Specification	AXT424124A

Connector Type	Header, Center Strip Contacts
Contact Finish	Gold
Features	Solder Retention
Height Above Board	0.049 in
Height Above Board	1.25 mm
Mated Stacking Heights	2.5 mm, 1.5 mm
Mounting Type	Surface Mount
Number of Positions	24
Number of Rows	2
Pitch [x]	0.016 in
Pitch [x]	0.4 mm

Part	Number of Positions	Mounting Type	Contact Finish	Height Above Board	Height Above Board	Connector Type	Features	Number of Rows	Pitch [x]	Pitch [x]	Mated Stacking Heights
Panasonic Electric Works AXT424124A	24	Surface Mount	Gold	0.049 in	1.25 mm	Header Center Strip Contacts	Solder Retention	2	0.016 in	0.4 mm	1.5 mm 2.5 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Strip	500	$ 1.12

General part information

24 Position Connector Header, Center Strip Contacts Surface Mount Gold
