TSM9120EXK+T

Obsolete

Silicon Labs

IC COMPARATOR 1 GEN PUR SC70-5

Search across all available documentation for this part.

Obsolete

Silicon Labs

IC COMPARATOR 1 GEN PUR SC70-5

Technical Specifications

Parameters and characteristics for this part

Specification	TSM9120EXK+T

CMRR, PSRR (Typ)	80 dB, 66.02 dB
Current - Input Bias (Max) [Max]	0.001 µA
Current - Output (Typ)	50 mA
Current - Quiescent (Max) [Max]	800 nA
Hysteresis	4 mV
Mounting Type	Surface Mount
Number of Elements	1
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Output Type	Open-Drain
Package / Case	SC-70-5, 5-TSSOP, SOT-353
Propagation Delay (Max) [Max]	45 µs
Supplier Device Package	SC-70-5
Type	General Purpose
Voltage - Input Offset (Max) [Max]	5 mV
Voltage - Supply, Single/Dual (±) [Max]	5.5 V
Voltage - Supply, Single/Dual (±) [Min]	1.6 V

Part	Propagation Delay (Max) [Max]	Current - Quiescent (Max) [Max]	Voltage - Supply, Single/Dual (±) [Min]	Voltage - Supply, Single/Dual (±) [Max]	Output Type	Voltage - Input Offset (Max) [Max]	Package / Case	Mounting Type	Type	Hysteresis	Operating Temperature [Max]	Operating Temperature [Min]	CMRR, PSRR (Typ)	Current - Input Bias (Max) [Max]	Supplier Device Package	Current - Output (Typ)	Number of Elements
Silicon Labs TSM9120EXK+T	45 µs	800 nA	1.6 V	5.5 V	Open-Drain	5 mV	5-TSSOP SC-70-5 SOT-353	Surface Mount	General Purpose	4 mV	85 °C	-40 °C	66.02 dB 80 dB	0.001 µA	SC-70-5	50 mA	1
Silicon Labs TSM9120EXK+T	45 µs	800 nA	1.6 V	5.5 V	Open-Drain	5 mV	6-VSSOP (5 Lead) SC-88A SOT-353	Surface Mount	General Purpose	4 mV	85 °C	-40 °C	66.02 dB 80 dB	0.001 µA	SC-70-5	50 mA	1

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Comparator General Purpose Open-Drain SC-70-5
