PB2L42D1100
ActiveE-Switch
SWITCH PUSHBUTTON DPST 20A 125V
Deep-Dive with AI
Search across all available documentation for this part.
PB2L42D1100
ActiveE-Switch
SWITCH PUSHBUTTON DPST 20A 125V
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | PB2L42D1100 |
|---|---|
| Actuator Marking | No Marking |
| Actuator Type | Dual, Square, Button |
| Circuit | DPST |
| Color - Actuator/Cap | Black |
| Current Rating (Amps) | 20 A |
| Electrical Life | 10000 Cycles |
| Features | Safety Lock |
| Ingress Protection | IP54 - Dust Protected, Water Resistant |
| Mounting Type | Panel Mount, Snap-In |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -20 C |
| Panel Cutout Dimensions [x] | 30 mm |
| Panel Cutout Dimensions [y] | 22 mm |
| Switch Function | Off-On |
| Termination Style | Quick Connect - 0.250" (6.3mm) |
| Type | Standard |
| Voltage Rating - AC | 125 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 5.51 | |
| 10 | $ 4.91 | |||
| 25 | $ 4.65 | |||
| 50 | $ 4.48 | |||
| 100 | $ 4.27 | |||
| 250 | $ 4.08 | |||
Description
General part information
PB2L42 Series
Pushbutton Switch DPST Standard Panel Mount, Snap-In
Documents
Technical documentation and resources
No documents available
