Q-2O037000D.75M

Active

Amphenol Custom Cable

CBL ASSY SMA-NTYPE PLG-PL 29.53"

Deep-Dive with AI

Search across all available documentation for this part.

Q-2O037000D.75M

Active

Amphenol Custom Cable

CBL ASSY SMA-NTYPE PLG-PL 29.53"

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	Q-2O037000D.75M

1st Connector	SMA Plug, Right Angle
1st Connector Mounting Type	Free Hanging (In-Line)
1st Contact Gender	Male
2nd Connector	N-Type Plug
2nd Connector Mounting Type	Free Hanging (In-Line)
2nd Contact Gender	Male
Cable Type	LMR 195
Color	Black
Features	Shielded
Frequency - Max [Max]	6000 MHz
Length	29.53 "
Length	750 mm
Overall Impedance	50 Ohms
Style	SMA to N-Type

Q-2O0370 Series

Part	Cable Type	1st Connector	Overall Impedance	Style	Frequency - Max [Max]	1st Contact Gender	2nd Connector	Length	Length	1st Connector Mounting Type	2nd Contact Gender	2nd Connector Mounting Type	Color	Features	Length
Amphenol Custom Cable Q-2O037000D036i	LMR 195	Right Angle SMA Plug	50 Ohms	SMA to N-Type	6000 MHz	Male	N-Type Plug	91.44 cm	36 in	Free Hanging (In-Line)	Male	Free Hanging (In-Line)	Black	Shielded
Amphenol Custom Cable Q-2O037000D012i	LMR 195	Right Angle SMA Plug	50 Ohms	SMA to N-Type	6000 MHz	Male	N-Type Plug	304.8 mm	12 "	Free Hanging (In-Line)	Male	Free Hanging (In-Line)	Black	Shielded
Amphenol Custom Cable Q-2O037000D072i	LMR 195	Right Angle SMA Plug	50 Ohms	SMA to N-Type	6000 MHz	Male	N-Type Plug	1.8 m	72 in	Free Hanging (In-Line)	Male	Free Hanging (In-Line)	Black	Shielded	6 ft
Amphenol Custom Cable Q-2O037000D002M	LMR 195	Right Angle SMA Plug	50 Ohms	SMA to N-Type	6000 MHz	Male	N-Type Plug	2 m	78.7 in	Free Hanging (In-Line)	Male	Free Hanging (In-Line)	Black	Shielded	6.6 ft
Amphenol Custom Cable Q-2O037000D024i	LMR 195	Right Angle SMA Plug	50 Ohms	SMA to N-Type	6000 MHz	Male	N-Type Plug	609.6 mm	24 "	Free Hanging (In-Line)	Male	Free Hanging (In-Line)	Black	Shielded
Amphenol Custom Cable Q-2O037000D.75M	LMR 195	Right Angle SMA Plug	50 Ohms	SMA to N-Type	6000 MHz	Male	N-Type Plug	750 mm	29.53 "	Free Hanging (In-Line)	Male	Free Hanging (In-Line)	Black	Shielded
Amphenol Custom Cable Q-2O037000D108i	LMR 195	Right Angle SMA Plug	50 Ohms	SMA to N-Type	6000 MHz	Male	N-Type Plug	2.7 m	108 in	Free Hanging (In-Line)	Male	Free Hanging (In-Line)	Black	Shielded	9 ft
Amphenol Custom Cable Q-2O037000D006i	LMR 195	Right Angle SMA Plug	50 Ohms	SMA to N-Type	6000 MHz	Male	N-Type Plug	152.4 mm	6 in	Free Hanging (In-Line)	Male	Free Hanging (In-Line)	Black	Shielded
Amphenol Custom Cable Q-2O037000D0.5M	LMR 195	Right Angle SMA Plug	50 Ohms	SMA to N-Type	6000 MHz	Male	N-Type Plug	50 cm	19.69 "	Free Hanging (In-Line)	Male	Free Hanging (In-Line)	Black	Shielded
Amphenol Custom Cable Q-2O037000D2.5M	LMR 195	Right Angle SMA Plug	50 Ohms	SMA to N-Type	6000 MHz	Male	N-Type Plug	2.5 m	98.4 in	Free Hanging (In-Line)	Male	Free Hanging (In-Line)	Black	Shielded	8.2 '

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bag	1	$ 87.37
		25	$ 85.67
		50	$ 83.98
		100	$ 82.28
		250	$ 80.59

Description

General part information

Q-2O0370 Series

Cable Assembly Coaxial SMA to N-Type LMR 195 29.53" (750.00mm)

Documents

Technical documentation and resources

No documents available
