LT3990EMSE-3.3#PBF
ActiveAnalog Devices Inc
62V, 350MA STEP-DOWN REGULATOR WITH 2.5µA QUIESCENT CURRENT AND INTEGRATED DIODES
Deep-Dive with AI
Search across all available documentation for this part.
LT3990EMSE-3.3#PBF
ActiveAnalog Devices Inc
62V, 350MA STEP-DOWN REGULATOR WITH 2.5µA QUIESCENT CURRENT AND INTEGRATED DIODES
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | LT3990EMSE-3.3#PBF | LT3990 Series |
|---|---|---|
| Current - Output | 350 mA | 350 mA |
| Frequency - Switching [Max] | 2.3 MHz | 2.3 MHz |
| Frequency - Switching [Min] | 210 kHz | 210 kHz |
| Function | Step-Down | Step-Down |
| Mounting Type | Surface Mount | Surface Mount |
| Number of Outputs | 1 | 1 |
| Operating Temperature [Max] | 125 ¯C | 125 - 150 ¯C |
| Operating Temperature [Min] | -40 °C | -40 °C |
| Output Configuration | Positive | Positive |
| Output Type | 27.03 °C/W | 27.03 °C/W |
| Output Type | - | Adjustable |
| Package / Case | 0.118 in, 3 mm | 0.118 - 3 in |
| Package / Case | 16-TFSOP | 16-TFSOP, 10-WFDFN Exposed Pad |
| Supplier Device Package | 16-MSOP-EP | 16-MSOP-EP, 10-DFN (3x3) |
| Synchronous Rectifier | False | False |
| Topology | Buck | Buck |
| Voltage - Input (Max) [Max] | 62 V | 62 V |
| Voltage - Input (Min) [Min] | 4.2 V | 4.2 V |
| Voltage - Output (Max) | - | 25 V |
| Voltage - Output (Min/Fixed) | 3.3 V | 1.21 - 5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
LT3990 Series
62V, 350mA Step-Down Regulator with 2.5μA Quiescent Current and Integrated Diodes
| Part | Function | Mounting Type | Topology | Voltage - Output (Min/Fixed) | Number of Outputs | Supplier Device Package | Current - Output | Voltage - Output (Max) [Max] | Package / Case | Package / Case | Voltage - Input (Max) [Max] | Voltage - Input (Min) [Min] | Output Type | Operating Temperature [Max] | Operating Temperature [Min] | Frequency - Switching [Min] | Frequency - Switching [Max] | Output Configuration | Synchronous Rectifier | Output Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc LT3990IMSE#PBFThe LT3990 is an adjustable frequency monolithic buck switching regulator that accepts a wide input voltage range up to 62V, and consumes only 2.5μA of quiescent current. A high efficiency switch is included on the die along with the catch diode, boost diode, and the necessary oscillator, control and logic circuitry. Low ripple Burst Mode operation maintains high efficiency at low output currents while keeping the output ripple below 5mV in a typical application. Current mode topology is used for fast transient response and good loop stability. A catch diode current limit provides protection against shorted outputs and overvoltage conditions. An accurate programmable undervoltage lockout feature is available, producing a low shutdown current of 0.7μA. A power good flag signals when VOUTreaches 90% of the programmed output voltage. The LT3990 is available in small, thermally enhanced 16-pin MSOP and 3mm × 3mm DFN packages.APPLICATIONSAutomotive Battery RegulationPower for Portable ProductsIndustrial Supplies | Step-Down | Surface Mount | Buck | 1.21 V | 1 | 16-MSOP-EP | 350 mA | 25 V | 0.118 in, 3 mm | 16-TFSOP | 62 V | 4.2 V | Adjustable | 125 ¯C | -40 °C | 210 kHz | 2.3 MHz | Positive | ||
Analog Devices Inc LT3990EDD#PBFThe LT3990 is an adjustable frequency monolithic buck switching regulator that accepts a wide input voltage range up to 62V, and consumes only 2.5μA of quiescent current. A high efficiency switch is included on the die along with the catch diode, boost diode, and the necessary oscillator, control and logic circuitry. Low ripple Burst Mode operation maintains high efficiency at low output currents while keeping the output ripple below 5mV in a typical application. Current mode topology is used for fast transient response and good loop stability. A catch diode current limit provides protection against shorted outputs and overvoltage conditions. An accurate programmable undervoltage lockout feature is available, producing a low shutdown current of 0.7μA. A power good flag signals when VOUTreaches 90% of the programmed output voltage. The LT3990 is available in small, thermally enhanced 16-pin MSOP and 3mm × 3mm DFN packages.APPLICATIONSAutomotive Battery RegulationPower for Portable ProductsIndustrial Supplies | Step-Down | Surface Mount | Buck | 1.21 V | 1 | 10-DFN (3x3) | 350 mA | 25 V | 10-WFDFN Exposed Pad | 62 V | 4.2 V | Adjustable | 125 ¯C | -40 °C | 210 kHz | 2.3 MHz | Positive | |||
Analog Devices Inc LT3990HMSE-3.3#PBFThe LT3990 is an adjustable frequency monolithic buck switching regulator that accepts a wide input voltage range up to 62V, and consumes only 2.5μA of quiescent current. A high efficiency switch is included on the die along with the catch diode, boost diode, and the necessary oscillator, control and logic circuitry. Low ripple Burst Mode operation maintains high efficiency at low output currents while keeping the output ripple below 5mV in a typical application. Current mode topology is used for fast transient response and good loop stability. A catch diode current limit provides protection against shorted outputs and overvoltage conditions. An accurate programmable undervoltage lockout feature is available, producing a low shutdown current of 0.7μA. A power good flag signals when VOUTreaches 90% of the programmed output voltage. The LT3990 is available in small, thermally enhanced 16-pin MSOP and 3mm × 3mm DFN packages.APPLICATIONSAutomotive Battery RegulationPower for Portable ProductsIndustrial Supplies | Step-Down | Surface Mount | Buck | 3.3 V | 1 | 16-MSOP-EP | 350 mA | 0.118 in, 3 mm | 16-TFSOP | 62 V | 4.2 V | 150 C | -40 °C | 210 kHz | 2.3 MHz | Positive | 27.03 °C/W | |||
Analog Devices Inc LT3990IDD#PBFThe LT3990 is an adjustable frequency monolithic buck switching regulator that accepts a wide input voltage range up to 62V, and consumes only 2.5μA of quiescent current. A high efficiency switch is included on the die along with the catch diode, boost diode, and the necessary oscillator, control and logic circuitry. Low ripple Burst Mode operation maintains high efficiency at low output currents while keeping the output ripple below 5mV in a typical application. Current mode topology is used for fast transient response and good loop stability. A catch diode current limit provides protection against shorted outputs and overvoltage conditions. An accurate programmable undervoltage lockout feature is available, producing a low shutdown current of 0.7μA. A power good flag signals when VOUTreaches 90% of the programmed output voltage. The LT3990 is available in small, thermally enhanced 16-pin MSOP and 3mm × 3mm DFN packages.APPLICATIONSAutomotive Battery RegulationPower for Portable ProductsIndustrial Supplies | Step-Down | Surface Mount | Buck | 1.21 V | 1 | 10-DFN (3x3) | 350 mA | 25 V | 10-WFDFN Exposed Pad | 62 V | 4.2 V | Adjustable | 125 ¯C | -40 °C | 210 kHz | 2.3 MHz | Positive | |||
Analog Devices Inc LT3990HMSE-5#PBFThe LT3990 is an adjustable frequency monolithic buck switching regulator that accepts a wide input voltage range up to 62V, and consumes only 2.5μA of quiescent current. A high efficiency switch is included on the die along with the catch diode, boost diode, and the necessary oscillator, control and logic circuitry. Low ripple Burst Mode operation maintains high efficiency at low output currents while keeping the output ripple below 5mV in a typical application. Current mode topology is used for fast transient response and good loop stability. A catch diode current limit provides protection against shorted outputs and overvoltage conditions. An accurate programmable undervoltage lockout feature is available, producing a low shutdown current of 0.7μA. A power good flag signals when VOUTreaches 90% of the programmed output voltage. The LT3990 is available in small, thermally enhanced 16-pin MSOP and 3mm × 3mm DFN packages.APPLICATIONSAutomotive Battery RegulationPower for Portable ProductsIndustrial Supplies | Step-Down | Surface Mount | Buck | 5 V | 1 | 16-MSOP-EP | 350 mA | 0.118 in, 3 mm | 16-TFSOP | 62 V | 4.2 V | 150 C | -40 °C | 210 kHz | 2.3 MHz | Positive | 27.03 °C/W | |||
Analog Devices Inc LT3990EMSE-3.3#PBFThe LT3990 is an adjustable frequency monolithic buck switching regulator that accepts a wide input voltage range up to 62V, and consumes only 2.5μA of quiescent current. A high efficiency switch is included on the die along with the catch diode, boost diode, and the necessary oscillator, control and logic circuitry. Low ripple Burst Mode operation maintains high efficiency at low output currents while keeping the output ripple below 5mV in a typical application. Current mode topology is used for fast transient response and good loop stability. A catch diode current limit provides protection against shorted outputs and overvoltage conditions. An accurate programmable undervoltage lockout feature is available, producing a low shutdown current of 0.7μA. A power good flag signals when VOUTreaches 90% of the programmed output voltage. The LT3990 is available in small, thermally enhanced 16-pin MSOP and 3mm × 3mm DFN packages.APPLICATIONSAutomotive Battery RegulationPower for Portable ProductsIndustrial Supplies | Step-Down | Surface Mount | Buck | 3.3 V | 1 | 16-MSOP-EP | 350 mA | 0.118 in, 3 mm | 16-TFSOP | 62 V | 4.2 V | 125 ¯C | -40 °C | 210 kHz | 2.3 MHz | Positive | 27.03 °C/W | |||
Analog Devices Inc LT3990EDD#TRPBFThe LT3990 is an adjustable frequency monolithic buck switching regulator that accepts a wide input voltage range up to 62V, and consumes only 2.5μA of quiescent current. A high efficiency switch is included on the die along with the catch diode, boost diode, and the necessary oscillator, control and logic circuitry. Low ripple Burst Mode operation maintains high efficiency at low output currents while keeping the output ripple below 5mV in a typical application. Current mode topology is used for fast transient response and good loop stability. A catch diode current limit provides protection against shorted outputs and overvoltage conditions. An accurate programmable undervoltage lockout feature is available, producing a low shutdown current of 0.7μA. A power good flag signals when VOUTreaches 90% of the programmed output voltage. The LT3990 is available in small, thermally enhanced 16-pin MSOP and 3mm × 3mm DFN packages.APPLICATIONSAutomotive Battery RegulationPower for Portable ProductsIndustrial Supplies | Step-Down | Surface Mount | Buck | 1.21 V | 1 | 10-DFN (3x3) | 350 mA | 25 V | 10-WFDFN Exposed Pad | 62 V | 4.2 V | Adjustable | 125 ¯C | -40 °C | 210 kHz | 2.3 MHz | Positive | |||
Analog Devices Inc LT3990IMSE-3.3#TRPBFThe LT3990 is an adjustable frequency monolithic buck switching regulator that accepts a wide input voltage range up to 62V, and consumes only 2.5μA of quiescent current. A high efficiency switch is included on the die along with the catch diode, boost diode, and the necessary oscillator, control and logic circuitry. Low ripple Burst Mode operation maintains high efficiency at low output currents while keeping the output ripple below 5mV in a typical application. Current mode topology is used for fast transient response and good loop stability. A catch diode current limit provides protection against shorted outputs and overvoltage conditions. An accurate programmable undervoltage lockout feature is available, producing a low shutdown current of 0.7μA. A power good flag signals when VOUTreaches 90% of the programmed output voltage. The LT3990 is available in small, thermally enhanced 16-pin MSOP and 3mm × 3mm DFN packages.APPLICATIONSAutomotive Battery RegulationPower for Portable ProductsIndustrial Supplies | Step-Down | Surface Mount | Buck | 3.3 V | 1 | 16-MSOP-EP | 350 mA | 0.118 in, 3 mm | 16-TFSOP | 62 V | 4.2 V | 125 ¯C | -40 °C | 210 kHz | 2.3 MHz | Positive | 27.03 °C/W | |||
Analog Devices Inc LT3990IMSE-5#TRPBFThe LT3990 is an adjustable frequency monolithic buck switching regulator that accepts a wide input voltage range up to 62V, and consumes only 2.5μA of quiescent current. A high efficiency switch is included on the die along with the catch diode, boost diode, and the necessary oscillator, control and logic circuitry. Low ripple Burst Mode operation maintains high efficiency at low output currents while keeping the output ripple below 5mV in a typical application. Current mode topology is used for fast transient response and good loop stability. A catch diode current limit provides protection against shorted outputs and overvoltage conditions. An accurate programmable undervoltage lockout feature is available, producing a low shutdown current of 0.7μA. A power good flag signals when VOUTreaches 90% of the programmed output voltage. The LT3990 is available in small, thermally enhanced 16-pin MSOP and 3mm × 3mm DFN packages.APPLICATIONSAutomotive Battery RegulationPower for Portable ProductsIndustrial Supplies | Step-Down | Surface Mount | Buck | 5 V | 1 | 16-MSOP-EP | 350 mA | 0.118 in, 3 mm | 16-TFSOP | 62 V | 4.2 V | 125 ¯C | -40 °C | 210 kHz | 2.3 MHz | Positive | 27.03 °C/W | |||
Analog Devices Inc LT3990EMSE#TRPBFThe LT3990 is an adjustable frequency monolithic buck switching regulator that accepts a wide input voltage range up to 62V, and consumes only 2.5μA of quiescent current. A high efficiency switch is included on the die along with the catch diode, boost diode, and the necessary oscillator, control and logic circuitry. Low ripple Burst Mode operation maintains high efficiency at low output currents while keeping the output ripple below 5mV in a typical application. Current mode topology is used for fast transient response and good loop stability. A catch diode current limit provides protection against shorted outputs and overvoltage conditions. An accurate programmable undervoltage lockout feature is available, producing a low shutdown current of 0.7μA. A power good flag signals when VOUTreaches 90% of the programmed output voltage. The LT3990 is available in small, thermally enhanced 16-pin MSOP and 3mm × 3mm DFN packages.APPLICATIONSAutomotive Battery RegulationPower for Portable ProductsIndustrial Supplies | Step-Down | Surface Mount | Buck | 1.21 V | 1 | 16-MSOP-EP | 350 mA | 25 V | 0.118 in, 3 mm | 16-TFSOP | 62 V | 4.2 V | Adjustable | 125 ¯C | -40 °C | 210 kHz | 2.3 MHz | Positive | ||
Analog Devices Inc LT3990IMSE#TRPBFThe LT3990 is an adjustable frequency monolithic buck switching regulator that accepts a wide input voltage range up to 62V, and consumes only 2.5μA of quiescent current. A high efficiency switch is included on the die along with the catch diode, boost diode, and the necessary oscillator, control and logic circuitry. Low ripple Burst Mode operation maintains high efficiency at low output currents while keeping the output ripple below 5mV in a typical application. Current mode topology is used for fast transient response and good loop stability. A catch diode current limit provides protection against shorted outputs and overvoltage conditions. An accurate programmable undervoltage lockout feature is available, producing a low shutdown current of 0.7μA. A power good flag signals when VOUTreaches 90% of the programmed output voltage. The LT3990 is available in small, thermally enhanced 16-pin MSOP and 3mm × 3mm DFN packages.APPLICATIONSAutomotive Battery RegulationPower for Portable ProductsIndustrial Supplies | Step-Down | Surface Mount | Buck | 1.21 V | 1 | 16-MSOP-EP | 350 mA | 25 V | 0.118 in, 3 mm | 16-TFSOP | 62 V | 4.2 V | Adjustable | 125 ¯C | -40 °C | 210 kHz | 2.3 MHz | Positive | ||
Analog Devices Inc LT3990HMSE#PBFThe LT3990 is an adjustable frequency monolithic buck switching regulator that accepts a wide input voltage range up to 62V, and consumes only 2.5μA of quiescent current. A high efficiency switch is included on the die along with the catch diode, boost diode, and the necessary oscillator, control and logic circuitry. Low ripple Burst Mode operation maintains high efficiency at low output currents while keeping the output ripple below 5mV in a typical application. Current mode topology is used for fast transient response and good loop stability. A catch diode current limit provides protection against shorted outputs and overvoltage conditions. An accurate programmable undervoltage lockout feature is available, producing a low shutdown current of 0.7μA. A power good flag signals when VOUTreaches 90% of the programmed output voltage. The LT3990 is available in small, thermally enhanced 16-pin MSOP and 3mm × 3mm DFN packages.APPLICATIONSAutomotive Battery RegulationPower for Portable ProductsIndustrial Supplies | Step-Down | Surface Mount | Buck | 1.21 V | 1 | 16-MSOP-EP | 350 mA | 25 V | 0.118 in, 3 mm | 16-TFSOP | 62 V | 4.2 V | Adjustable | 150 C | -40 °C | 210 kHz | 2.3 MHz | Positive | ||
Analog Devices Inc LT3990EMSE#PBFThe LT3990 is an adjustable frequency monolithic buck switching regulator that accepts a wide input voltage range up to 62V, and consumes only 2.5μA of quiescent current. A high efficiency switch is included on the die along with the catch diode, boost diode, and the necessary oscillator, control and logic circuitry. Low ripple Burst Mode operation maintains high efficiency at low output currents while keeping the output ripple below 5mV in a typical application. Current mode topology is used for fast transient response and good loop stability. A catch diode current limit provides protection against shorted outputs and overvoltage conditions. An accurate programmable undervoltage lockout feature is available, producing a low shutdown current of 0.7μA. A power good flag signals when VOUTreaches 90% of the programmed output voltage. The LT3990 is available in small, thermally enhanced 16-pin MSOP and 3mm × 3mm DFN packages.APPLICATIONSAutomotive Battery RegulationPower for Portable ProductsIndustrial Supplies | Step-Down | Surface Mount | Buck | 1.21 V | 1 | 16-MSOP-EP | 350 mA | 25 V | 0.118 in, 3 mm | 16-TFSOP | 62 V | 4.2 V | Adjustable | 125 ¯C | -40 °C | 210 kHz | 2.3 MHz | Positive |
Description
General part information
LT3990 Series
The LT3990 is an adjustable frequency monolithic buck switching regulator that accepts a wide input voltage range up to 62V, and consumes only 2.5μA of quiescent current. A high efficiency switch is included on the die along with the catch diode, boost diode, and the necessary oscillator, control and logic circuitry. Low ripple Burst Mode operation maintains high efficiency at low output currents while keeping the output ripple below 5mV in a typical application. Current mode topology is used for fast transient response and good loop stability. A catch diode current limit provides protection against shorted outputs and overvoltage conditions. An accurate programmable undervoltage lockout feature is available, producing a low shutdown current of 0.7μA. A power good flag signals when VOUTreaches 90% of the programmed output voltage. The LT3990 is available in small, thermally enhanced 16-pin MSOP and 3mm × 3mm DFN packages.APPLICATIONSAutomotive Battery RegulationPower for Portable ProductsIndustrial Supplies
