MAXM17635EVKIT#
ActiveAnalog Devices Inc./Maxim Integrated
EVAL MAXM17635
Deep-Dive with AI
Search across all available documentation for this part.
MAXM17635EVKIT#
ActiveAnalog Devices Inc./Maxim Integrated
EVAL MAXM17635
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | MAXM17635EVKIT# | MAXM17635 Series |
|---|---|---|
| Applications | - | ITE (Commercial) |
| Board Type | Fully Populated | Fully Populated |
| Current - Output | 2 A | 2 A |
| Current - Output (Max) | - | 2 A |
| Features | - | Adjustable Output |
| Frequency - Switching | 1.8 MHz | 1.8 MHz |
| Main Purpose | DC/DC, Step Down | DC/DC, Step Down |
| Mounting Type | - | Surface Mount |
| Number of Outputs | - | 1 |
| Operating Temperature | - | 125 °C |
| Operating Temperature | - | -40 °C |
| Outputs and Type | Non-Isolated | Non-Isolated |
| Outputs and Type | 1 | 1 |
| Package / Case | - | 24-SMD Module Exposed Pad |
| Regulator Topology | Buck | Buck |
| Supplied Contents | Board(s) | Board(s) |
| Supplier Device Package | - | 24-eMGA (4x4) |
| Type | - | Non-Isolated PoL Module |
| Utilized IC / Part | MAXM17635 | MAXM17635 |
| Voltage - Input (Max) | - | 36 V |
| Voltage - Input (Min) | - | 4.5 V |
| Voltage - Input [Max] | 36 V | 36 V |
| Voltage - Input [Min] | 18 V | 18 V |
| Voltage - Output | 12 V | 12 V |
| Voltage - Output 1 | - | 0.9 V |
| Voltage - Output 1 | - | 12 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 40.12 | |
MAXM17635 Series
EVAL MAXM17635
| Part | Main Purpose | Supplied Contents | Utilized IC / Part | Current - Output | Board Type | Frequency - Switching | Outputs and Type | Outputs and Type | Voltage - Input [Max] | Voltage - Input [Min] | Voltage - Output | Regulator Topology | Supplier Device Package | Package / Case | Mounting Type | Applications | Number of Outputs | Voltage - Output 1 [Min] | Voltage - Output 1 [Max] | Voltage - Input (Max) [Max] | Operating Temperature [Max] | Operating Temperature [Min] | Current - Output (Max) [Max] | Type | Features | Voltage - Input (Min) [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated MAXM17635EVKIT# | DC/DC, Step Down | Board(s) | MAXM17635 | 2 A | Fully Populated | 1.8 MHz | Non-Isolated | 1 | 36 V | 18 V | 12 V | Buck | ||||||||||||||
Analog Devices Inc./Maxim Integrated MAXM17635AMG+ | 24-eMGA (4x4) | 24-SMD Module Exposed Pad | Surface Mount | |||||||||||||||||||||||
Analog Devices Inc./Maxim Integrated MAXM17635AMG+T | 24-eMGA (4x4) | 24-SMD Module Exposed Pad | Surface Mount | ITE (Commercial) | 1 | 0.9 V | 12 V | 36 V | 125 °C | -40 °C | 2 A | Non-Isolated PoL Module | Adjustable Output | 4.5 V |
Description
General part information
MAXM17635 Series
MAXM17635 Himalaya DC/DC, Step Down 1, Non-Isolated Outputs Evaluation Board
