XLM2ACR169W
ActiveSunLED
LED RED CLEAR 5MM ROUND T/H
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
XLM2ACR169W
ActiveSunLED
LED RED CLEAR 5MM ROUND T/H
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | XLM2ACR169W |
|---|---|
| Color | Red |
| Configuration | Standard |
| Current - Test | 20 mA |
| Height (Max) [Max] [z] | 4.85 mm |
| Lens Color | Colorless |
| Lens Size [diameter] | 4.8 mm Dia |
| Lens Style | Round with Domed Top |
| Lens Transparency | Clear |
| Millicandela Rating | 695 mcd |
| Mounting Type | Through Hole |
| Package / Case | Radial |
| Supplier Device Package [diameter] | 5 mm |
| Viewing Angle | 130 ° |
| Voltage - Forward (Vf) (Typ) | 2.2 V |
| Wavelength - Dominant | 625 nm |
| Wavelength - Peak [custom] | 640 nm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 0.83 | |
| 10 | $ 0.54 | |||
| 100 | $ 0.35 | |||
| 1000 | $ 0.28 | |||
| 2000 | $ 0.26 | |||
| 5000 | $ 0.25 | |||
| 10000 | $ 0.25 | |||
| 25000 | $ 0.24 | |||
Description
General part information
XLM2ACR169 Series
Red 625nm LED Indication - Discrete 2.2V Radial
