C3216.41.86

Active

Prysmian Group

MULTI-PAIR 8COND 24AWG NAT 1000'

Search across all available documentation for this part.

Active

Prysmian Group

MULTI-PAIR 8COND 24AWG NAT 1000'

Technical Specifications

Parameters and characteristics for this part

Specification	C3216.41.86

Cable Type	Multi-Pair
Conductor Insulation	Fluoropolymer
Conductor Material	Copper, Tinned
Conductor Strand [custom]	32 AWG
Conductor Strand [custom]	7
Jacket (Insulation) Diameter [diameter]	5.11 mm
Jacket (Insulation) Diameter [diameter]	0.201 in
Jacket (Insulation) Thickness	0.0098 in
Jacket (Insulation) Thickness	0.25 mm
Jacket Color	Natural
Length	1000 ft
Length	304.8 m
Number of Conductors	8
Shield Coverage	100 %
Shield Material	Aluminum
Shield Type	Foil
Voltage	300 V
Wire Gauge	24 AWG

Part	Shield Material	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Conductor Strand [custom]	Conductor Strand [custom]	Voltage	Wire Gauge	Conductor Material	Shield Coverage	Number of Conductors	Length	Length	Jacket Color	Conductor Insulation	Shield Type	Cable Type	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness
Prysmian Group C3216.41.86	Aluminum	5.11 mm	0.201 in	32 AWG	7	300 V	24 AWG	Copper Tinned	100 %	8	1000 ft	304.8 m	Natural	Fluoropolymer	Foil	Multi-Pair	0.0098 in	0.25 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

8 (4 Pair Twisted) Conductor Multi-Pair Cable Natural 24 AWG Foil 1000.0' (304.8m)
