10-8-WN - 10-8-WN

10-8-WN

Active
3M

26-24 AWG NYLON INSULATED W/INSULATION GRIP RING TONGUE TERMIN

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet
10-8-WN - 10-8-WN

10-8-WN

Active
3M

26-24 AWG NYLON INSULATED W/INSULATION GRIP RING TONGUE TERMIN

Deep-Dive with AI

DocumentsDatasheet

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification10-8-WN10-8 Series
Color-Yellow
Features-Brazed Seam
Insulation-Insulated
Material - Insulation-Nylon, Polyamide (PA)
Mounting Type-Free Hanging (In-Line)
null-
Stud/Tab Size-8 Stud
Terminal Type-Circular
Termination-Crimp
Wire Gauge-22 AWG
Wire Gauge-26 AWG

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

DistributorPackageQuantity$
DigikeyBulk 1$ 0.93
10$ 0.71
25$ 0.63
50$ 0.59
100$ 0.54
250$ 0.49
500$ 0.45
1000$ 0.42
2500$ 0.38
NewarkEach 1000$ 0.47
1000$ 0.47

10-8 Series

26-24 AWG NYLON INSULATED W/INSULATION GRIP RING TONGUE TERMIN

PartInsulationTerminationColorFeaturesMaterial - InsulationMounting TypeTerminal TypeStud/Tab SizeWire Gauge [Min]Wire Gauge [Max]
3M
10-8-WN
Insulated
Crimp
Yellow
Brazed Seam
Nylon, Polyamide (PA)
Free Hanging (In-Line)
Circular
8 Stud
22 AWG
26 AWG
3M
10-8-WN

Description

General part information

10-8 Series

Ring Terminal Connector 8 Stud Circular 22-26 AWG Crimp
