EZ240D18RS

Active

Sensata-Crydom

SSR RELAY SPST-NO 18A 24-280V

Search across all available documentation for this part.

Active

Sensata-Crydom

SSR RELAY SPST-NO 18A 24-280V

Technical Specifications

Parameters and characteristics for this part

Part	Approval Agency	Mounting Type	Load Current	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Load [Min]	Voltage - Load [Max]	Termination Style	Voltage - Input [Max]	Voltage - Input [Min]	Output Type	Package / Case	Circuit
Sensata-Crydom EZ240D18R	CE CSA cURus TUV	Chassis Mount	18 A	-40 °C	80 C	24 V	280 V	Quick Connect - 0.250" (6.3mm)	15 V	3 V	AC	Module
Sensata-Crydom EZ240D18-B	CE CSA cURus TUV	Chassis Mount	18 A	-40 °C	80 C	24 V	280 V	Quick Connect - 0.250" (6.3mm)	15 V	3 V	AC Zero Cross	Module	SPST-NC (1 Form B)
Sensata-Crydom EZ240D18RS	CE CSA cURus TUV	Chassis Mount	18 A	-40 °C	80 C	24 V	280 V	Quick Connect - 0.250" (6.3mm)	15 V	3 V	AC	Module
Sensata-Crydom EZ240D12	CE CSA cURus TUV	Chassis Mount	12 A	-40 °C	80 C	24 V	280 V	Quick Connect - 0.250" (6.3mm)	15 V	3 V	AC Zero Cross	Module
Sensata-Crydom EZ240D18S	CE CSA cURus TUV	Chassis Mount	18 A	-40 °C	80 C	24 V	280 V	Quick Connect - 0.250" (6.3mm)	15 V	3 V	AC Zero Cross	Module
