ZM-4047-CW

Obsolete

JKL Components Corp.

LED ENG CL WHT LNR STRIP 7500K

Search across all available documentation for this part.

Obsolete

JKL Components Corp.

LED ENG CL WHT LNR STRIP 7500K

Technical Specifications

Parameters and characteristics for this part

Specification	ZM-4047-CW

CCT (K)	7500 K
Color	Cool, White
Configuration	Linear Light Strip, Flexible
Current - Max [Max]	110 mA
Current - Test	100 mA
Height [z]	8 mm
Lens Type	Flat
Lumens/Watt @ Current - Test	43 lm/W
Luminous Flux @ Current/Temperature	52 lm
Size / Dimension [x]	40 mm
Size / Dimension [y]	47.6 mm
Type	LED Engine
Viewing Angle	120 °
Voltage - Forward (Vf) (Typ)	12 V

Part	Type	Current - Max [Max]	Size / Dimension [y]	Size / Dimension [x]	Color	CCT (K)	Lumens/Watt @ Current - Test	Height [z]	Viewing Angle	Luminous Flux @ Current/Temperature	Lens Type	Configuration	Current - Test	Voltage - Forward (Vf) (Typ)
JKL Components Corp. ZM-4047-CW	LED Engine	110 mA	47.6 mm	40 mm	Cool White	7500 K	43 lm/W	8 mm	120 °	52 lm	Flat	Flexible Linear Light Strip	100 mA	12 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

LED Lighting COBs Engines Modules LED Engine - White, Cool Linear Light Strip, Flexible
