1712248011

1712248011

Active
Molex

ZSFP+ STACKED GANGED ASSEMBLY WITH METAL SPRING FINGERS, 2-BY-8 WITH 4 LIGHT PIPES, 320 CIRCUITS

Find alt
1712248011

1712248011

Active
Molex

ZSFP+ STACKED GANGED ASSEMBLY WITH METAL SPRING FINGERS, 2-BY-8 WITH 4 LIGHT PIPES, 320 CIRCUITS

Find alt

Description

General part information

171224 Series

320 (20 x 16) Position zSFP+ Receptacle with Cage, Ganged (2x8) Connector Press-Fit Through Hole, Right Angle

Technical Specifications

Parameters and characteristics for this part

Specification1712248011
Connector Pin Configuration (Columns)8 pins
Connector Pin Configuration (Rows)2 pins
Connector StyleReceptacle with Cage, Ganged
Connector TypezSFP+
Contact FinishGold
Contact Finish Thickness30 µin
FeaturesEMI Shielded, Light Pipe, Board Guide
Mounting TypeThrough Hole, Right Angle
Number of Positions (Columns)20
Number of Positions (Rows)16
Number of Positions (Total)320
TerminationPress-Fit
