TMC4210-I-T
ActiveAnalog Devices Inc./Maxim Integrated
IC MTR DRV BIPOLAR 3.3-5V 16SSOP
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
TMC4210-I-T
ActiveAnalog Devices Inc./Maxim Integrated
IC MTR DRV BIPOLAR 3.3-5V 16SSOP
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | TMC4210-I-T | TMC4210 Series |
|---|---|---|
| Applications | General Purpose | General Purpose |
| Function | Controller - Commutation, Direction Management | Controller - Commutation, Direction Management |
| Interface | SPI | SPI |
| Motor Type - Stepper | Bipolar | Bipolar |
| Mounting Type | Surface Mount | Surface Mount |
| Operating Temperature [Max] | 105 °C | 105 °C |
| Operating Temperature [Min] | -40 °C | -40 °C |
| Output Configuration | Step/Direction | Step/Direction |
| Package / Case | 0.154 in | 0.154 in |
| Package / Case | 16-SSOP | 16-SSOP |
| Package / Case | 3.9 mm | 3.9 mm |
| Step Resolution | >256 | >256 |
| Supplier Device Package | 16-SSOP | 16-SSOP |
| Technology | CMOS | CMOS |
| Voltage - Supply [Max] | 5 V | 5 V |
| Voltage - Supply [Min] | 3.3 V | 3.3 V |
