1452303-2
ActiveTE Connectivity Raychem Cable Protection
INL:R.BUM.MAL HSG12
Deep-Dive with AI
Search across all available documentation for this part.
1452303-2
ActiveTE Connectivity Raychem Cable Protection
INL:R.BUM.MAL HSG12
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 1452303-2 |
|---|---|
| Color | Green |
| Connector Type | Plug |
| Contact Termination | Crimp |
| Contact Type | Tab |
| Fastening Type | Latch Holder |
| Features | Sealed |
| Insulation Material | Polybutylene Terephthalate (PBT), Glass Filled |
| Mounting Type | Free Hanging (In-Line) |
| Number of Positions | 12 |
| Number of Rows | 3 |
| Operating Temperature [Max] | 120 °C |
| Operating Temperature [Min] | -40 °C |
| Row Spacing | 5.75 mm |
| Row Spacing | 0.226 in |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 3.06 | |
| 10 | $ 2.78 | |||
| 25 | $ 2.63 | |||
| 50 | $ 2.57 | |||
| 100 | $ 2.45 | |||
| 352 | $ 2.14 | |||
| 704 | $ 2.08 | |||
| 1056 | $ 1.78 | |||
| 2816 | $ 1.65 | |||
Description
General part information
1452303 Series
12 Rectangular Connectors - Housings Plug Green
Documents
Technical documentation and resources
No documents available
