Specification	APTGT50H120T3G

Configuration	Full Bridge Inverter
Current - Collector (Ic) (Max)	75 A
Current - Collector Cutoff (Max)	250 µA
IGBT Type	Trench Field Stop
Input	Standard
Input Capacitance (Cies) @ Vce	3.6 nF
Mounting Type	Chassis Mount
NTC Thermistor	Yes
Operating Temperature (Max)	150 °C
Operating Temperature (Min)	-40 °C
Package / Case	SP3
Package Name	SP3
Power - Max	270 W
Vce(on) (Max)	2.1 V
Voltage - Collector Emitter Breakdown (Max)	1200 V

APTGT50 Series

1700V/Triple Dual common source/IGBT modules

Part	Vce(on) (Max)	Current - Collector (Ic) (Max)	Package / Case	Mounting Type	Input	Package Name	IGBT Type	Power - Max	Current - Collector Cutoff (Max)	Operating Temperature (Max)	Operating Temperature (Min)	Voltage - Collector Emitter Breakdown (Max)	Input Capacitance (Cies) @ Vce	Configuration	NTC Thermistor
Microchip Technology APTGT50DH60T1G	1.9 V	80 A	SP1	Chassis Mount	Standard	SP1	Trench Field Stop	176 W	250 µA	175 °C	-40 °C	600 V	3.15 nF	Asymmetrical Bridge	Yes
Microchip Technology APTGT50H60T3G	1.9 V	80 A	SP3	Chassis Mount	Standard	SP3	Trench Field Stop	176 W	250 µA	175 °C	-40 °C	600 V	3.15 nF	Full Bridge Inverter	Yes
Microchip Technology APTGT50X60T3G	1.9 V	80 A	SP3	Chassis Mount	Standard	SP3	Trench Field Stop	176 W	250 µA	175 °C	-40 °C	600 V	3.15 nF	Three Phase Inverter	Yes
Microchip Technology APTGT50H170TG	2.4 V	75 A	SP4	Chassis Mount	Standard	SP4	Trench Field Stop	312 W	250 µA	150 °C	-40 °C	1700 V	4.4 nF	Full Bridge Inverter	Yes
Microchip Technology APTGT50A170TG	2.4 V	75 A	SP4	Chassis Mount	Standard	SP4	Trench Field Stop	312 W	250 µA	150 °C	-40 °C	1700 V	4.4 nF	Half Bridge	Yes
Microchip Technology APTGT50SK170T1G	2.4 V	75 A	SP1	Chassis Mount	Standard	SP1	Trench Field Stop	312 W	250 µA	150 °C	-40 °C	1700 V	4.4 nF	Single	Yes
Microchip Technology APTGT50A120T1G	2.1 V	75 A	SP1	Chassis Mount	Standard	SP1	Trench Field Stop	277 W	250 µA	150 °C	-40 °C	1200 V	3.6 nF	Half Bridge	Yes
Microchip Technology APTGT50DDA120T3G	2.1 V	75 A	SP3	Chassis Mount	Standard	SP3	Trench Field Stop	270 W	250 µA	175 °C	-40 °C	1200 V	3.6 nF	Dual Boost Chopper	Yes
Microchip Technology APTGT50TL60T3G	1.9 V	80 A	SP3	Chassis Mount	Standard	SP3	Trench Field Stop	176 W	250 µA	175 °C	-40 °C	600 V	3.15 nF	Three Level Inverter	Yes
Microchip Technology APTGT50DH120TG	2.1 V	75 A	SP4	Chassis Mount	Standard	SP4	Trench Field Stop	277 W	250 µA	150 °C	-40 °C	1200 V	3.6 nF	Asymmetrical Bridge	Yes

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

Mounting Instructions for SP1F and SP3F Power Modules

APTGT50H120T3G Datasheet
