SRP5020TA-1R2M

Active

Bourns Inc.

INDUCTOR, SHLD, 1.2UH, 6.2A, AEC-Q200

Search across all available documentation for this part.

Active

Bourns Inc.

INDUCTOR, SHLD, 1.2UH, 6.2A, AEC-Q200

Technical Specifications

Parameters and characteristics for this part

Part	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Mounting Type	Shielding	Frequency - Self Resonant	Q @ Freq	Operating Temperature [Min]	Operating Temperature [Max]	Package / Case	Inductance	Ratings	Current - Saturation (Isat)	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Type	DC Resistance (DCR)	Material - Core	Tolerance	Current Rating (Amps)	Inductance Frequency - Test	DC Resistance (DCR) [Max]
Bourns Inc. SRP5020TA-1R0M	5.2 mm	5.7 mm	0.205 "	0.224 in	Surface Mount	Shielded	64 MHz	13 100 kHz	-40 °C	105 ░C	Nonstandard	1 µH	AEC-Q200	13.7 A	2 mm	0.079 in	Drum Core Wirewound	20 mOhm	Metal	20 %	7 A	100 kHz
Bourns Inc. SRP5020TA-4R7M	5.2 mm	5.7 mm	0.205 "	0.224 in	Surface Mount	Shielded	30 MHz	18 100 kHz	-40 °C	105 ░C	Nonstandard	4.7 ÁH	AEC-Q200	5 A	2 mm	0.079 in	Drum Core Wirewound		Metal	20 %	2.8 A	100 kHz	116 mOhm
Bourns Inc. SRP5020TA-3R3M	5.2 mm	5.7 mm	0.205 "	0.224 in	Surface Mount	Shielded	35 MHz	17 100 kHz	-40 °C	105 ░C	Nonstandard	3.3 µH	AEC-Q200		2 mm	0.079 in	Drum Core Wirewound	76 mOhm	Metal	20 %	3.3 A	100 kHz
Bourns Inc. SRP5020TA-100M	5.2 mm	5.7 mm	0.205 "	0.224 in	Surface Mount	Shielded	18 MHz	22 100 kHz	-40 °C	105 ░C	Nonstandard	10 µH	AEC-Q200	3.4 A	2 mm	0.079 in	Drum Core Wirewound		Metal	20 %		100 kHz	199 mOhm
Bourns Inc. SRP5020TA-1R2M	5.2 mm	5.7 mm	0.205 "	0.224 in	Surface Mount	Shielded	58 MHz	14 100 kHz	-40 °C	105 ░C	Nonstandard	1.2 µH	AEC-Q200	11 A	2 mm	0.079 in	Drum Core Wirewound		Metal	20 %	6.2 A	100 kHz	28 mOhm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Cut Tape (CT)	1	$ 1.39
	Digi-Reel®	1	$ 1.39
	Tape & Reel (TR)	3000	$ 0.64
Newark	Each (Supplied on Cut Tape)	1	$ 0.88

General part information

1.2 µH Shielded Drum Core, Wirewound Inductor 6.2 A 28mOhm Max Nonstandard

Technical documentation and resources
