IL4117-X007

Active

Vishay General Semiconductor - Diodes Division

OPTOISOLATOR 5.3KV TRIAC 1CH

Search across all available documentation for this part.

Active

Vishay General Semiconductor - Diodes Division

OPTOISOLATOR 5.3KV TRIAC 1CH

Technical Specifications

Parameters and characteristics for this part

Specification	IL4117-X007

Approval Agency	BSI, cUR, CSA, UR, FIMKO
Current - DC Forward (If) (Max) [Max]	60 mA
Current - Hold (Ih)	200 µA
Current - LED Trigger (Ift) (Max) [Max]	1.3 mA
Current - On State (It (RMS)) (Max)	300 mA
Mounting Type	Surface Mount
Number of Channels	1
Operating Temperature [Max]	100 °C
Operating Temperature [Min]	-55 °C
Output Type	Triac
Package / Case	6-SMD
Static dV/dt (Min) [Min]	10 kV/µs
Turn On Time	35 µs
Voltage - Forward (Vf) (Typ)	1.3 V
Voltage - Isolation	5300 Vrms
Voltage - Off State	700 V
Zero Crossing Circuit	True

Part	Static dV/dt (Min) [Min]	Voltage - Off State	Voltage - Isolation	Current - On State (It (RMS)) (Max)	Current - Hold (Ih)	Mounting Type	Voltage - Forward (Vf) (Typ)	Output Type	Turn On Time	Approval Agency	Package / Case	Package / Case	Package / Case	Current - LED Trigger (Ift) (Max) [Max]	Zero Crossing Circuit	Current - DC Forward (If) (Max) [Max]	Number of Channels	Operating Temperature [Max]	Operating Temperature [Min]	Supplier Device Package
Vishay General Semiconductor - Diodes Division IL4117	10 kV/µs	700 V	5300 Vrms	300 mA	200 µA	Through Hole	1.3 V	Triac	35 µs	BSI CSA cUR FIMKO UR	6-DIP	0.3 in	7.62 mm	1.3 mA		60 mA	1	100 °C	-55 °C	6-DIP
Vishay General Semiconductor - Diodes Division IL4117-X007	10 kV/µs	700 V	5300 Vrms	300 mA	200 µA	Surface Mount	1.3 V	Triac	35 µs	BSI CSA cUR FIMKO UR	6-SMD			1.3 mA		60 mA	1	100 °C	-55 °C
