Specification	56995-501

Current - Max	9 A
Delta Tmax	67 °C
Features	Non-Sealed, Lead Wires
Height	5.59 mm
Maximum Power Dissipation (Qmax)	18.8 W
Number of Stages	1
Operating Temperature	80 °C
Resistance	350 mOhms
Size / Dimension Length	29.72 mm
Size / Dimension Shape	Square
Size / Dimension Width	29.72 mm
Voltage - Max	3.8 V

56995 Series

Part	Features	Size / Dimension Shape	Size / Dimension Length	Size / Dimension Width	Maximum Power Dissipation (Qmax)	Number of Stages	Current - Max	Delta Tmax	Voltage - Max	Operating Temperature	Resistance	Height
Laird Thermal Systems, Inc. 56995-501	Lead Wires Non-Sealed	Square	29.72 mm	29.72 mm	18.8 W	1	9 A	67 °C	3.8 V	80 °C	350 mOhms	5.59 mm
Laird Thermal Systems, Inc. 56995-503	Lead Wires Sealed Silicone RTV	Square	29.72 mm	29.72 mm	18.8 W	1	9 A	67 °C	3.8 V	80 °C	350 mOhms	5.59 mm
