MPC9352ACR2
ObsoleteRenesas Electronics Corporation
IC PLL CLOCK GENERATOR 32TQFP
MPC9352ACR2
ObsoleteRenesas Electronics Corporation
IC PLL CLOCK GENERATOR 32TQFP
Description
General part information
MPC9352 Series
The MPC9352 is a 3.3 V or 2.5 V compatible, 1:11 PLL based clock generator targeted for high performance clock tree applications. With output frequencies up to 200 MHz and output skews lower than 200 ps, the device meets the needs of most demanding clock applications.
Technical Specifications
Parameters and characteristics for this part
| Specification | MPC9352ACR2 |
|---|---|
| Differential Input | No |
| Differential Output | No |
| Divider | Yes |
| Frequency - Max | 200 MHz |
| Input | LVCMOS |
| Input Ratio | 1 |
| Mounting Type | Surface Mount |
| Multiplier | Yes |
| Number of Circuits | 1 |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Output | LVCMOS |
| Output Ratio | 11 |
| Package / Case | 32-LQFP |
| Package Length | 7 mm |
| Package Name | 32-TQFP |
| Package Width | 7 mm |
| PLL | Yes with Bypass |
| Type | PLL Clock Generator |
| Voltage - Supply (Maximum) | 3.465 V |
| Voltage - Supply (Minimum) | 2.375 V |
