M80-8070305 - M80-8070205

M80-8070305

Active
Harwin Inc.

3 POS. MALE SIL 22AWG CABLE CONN. KIT, NO LATCHES ROHS COMPLIANT: YES

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsM80, M83 Series Spec SheetM80-001+2
M80-8070305 - M80-8070205

M80-8070305

Active
Harwin Inc.

3 POS. MALE SIL 22AWG CABLE CONN. KIT, NO LATCHES ROHS COMPLIANT: YES

Deep-Dive with AI

DocumentsM80, M83 Series Spec SheetM80-001+2

Technical Specifications

Parameters and characteristics for this part

SpecificationM80-8070305
Cable TerminationCrimp
ColorBlack
Connector TypePlug
Contact FinishGold
Contact Finish Thickness10 Áin
Contact Finish Thickness0.25 Ám
Contact TypeMale Pin
Mounting TypeFree Hanging (In-Line)
Number of Rows1
Pitch [x]0.079 in
Pitch [x]2 mm
Wire Gauge22 AWG
Wire TypeDiscrete

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

DistributorPackageQuantity$
DigikeyBulk 500$ 2.35
NewarkEach 500$ 2.61
1000$ 2.39
2500$ 2.17

Description

General part information

M80-807 Series

3 Position Rectangular Plug Connector Crimp Gold 22 AWG
