IPG20N06S2L50AATMA1

Active

INFINEON’S IPG20N06S2L-50A DUAL N-CHANNEL MOSFET, 175°C, ROHS COMPLIANT, AEC Q101 QUALIFIED FOR AUTOMOTIVE. FIND DATA SHEET, PARAMETERS AND ORDERING INFORMATION.

Find alt

Alpha

IPG20N06S2L50AATMA1

Active

INFINEON

INFINEON’S IPG20N06S2L-50A DUAL N-CHANNEL MOSFET, 175°C, ROHS COMPLIANT, AEC Q101 QUALIFIED FOR AUTOMOTIVE. FIND DATA SHEET, PARAMETERS AND ORDERING INFORMATION.

Find alt

Alpha

Description Specifications Series Pricing CAD Documents

Description

General part information

IPG20N Series

Mosfet Array 55V 20A 51W Surface Mount, Wettable Flank PG-TDSON-8-10

Technical Specifications

Parameters and characteristics for this part

Specification	IPG20N06S2L50AATMA1

Channel Count	2
Configuration	N-Channel
Configuration - Features	Dual
Current - Continuous Drain (Id)	20 A
Drain to Source Voltage (Vdss)	55 V
FET Feature	Logic Level Gate
Gate Charge (Max)	17 nC
Grade	Automotive
Input Capacitance (Ciss) (Max)	560 pF
Mounting Type	Wettable Flank, Surface Mount
Operating Temperature (Max)	175 °C
Operating Temperature (Min)	-55 °C
Package / Case	8-PowerVDFN
Package Name	PG-TDSON-8-10
Power - Max	51 W
Qualification	AEC-Q101
Technology	MOSFET (Metal Oxide)
Vgs(th) (Max)	2 V

IPG20N Series

Part	Mounting Type	Qualification	Channel Count	Configuration	Configuration - Features	Current - Continuous Drain (Id)	Grade	FET Feature	Package Name	Power - Max	Package / Case	Rds On (Max)	Drain to Source Voltage (Vdss)	Gate Charge (Max)	Operating Temperature (Min)	Operating Temperature (Max)	Technology	Input Capacitance (Ciss) (Max)	Vgs(th) (Max)
INFINEON IPG20N06S2L35ATMA1	Surface Mount	AEC-Q101	2	N-Channel	Dual	20 A	Automotive	Logic Level Gate	PG-TDSON-8-4	65 VA	8-PowerVDFN	35 mOhm	55 V	23 nC	-55 °C	175 °C	MOSFET (Metal Oxide)	790 pF	2 V
INFINEON IPG20N06S2L50ATMA1	Surface Mount		2	N-Channel	Dual	20 A		Logic Level Gate	PG-TDSON-8-4	51 W	8-PowerVDFN		55 V	17 nC	-55 °C	175 °C	MOSFET (Metal Oxide)	560 pF	2 V
INFINEON IPG20N06S3L-35	Surface Mount		2	N-Channel	Dual	20 A		Logic Level Gate	PG-TDSON-8-4	30 W	8-PowerVDFN	35 mOhm	55 V	23 nC	-55 °C	175 °C	MOSFET (Metal Oxide)	1730 pF	2.2 V
INFINEON IPG20N04S4L07ATMA1	Surface Mount	AEC-Q101	2	N-Channel	Dual	20 A	Automotive	Logic Level Gate	PG-TDSON-8-4	65 VA	8-PowerVDFN	7.2 mOhm	40 V	50 nC	-55 °C	175 °C	MOSFET (Metal Oxide)	3980 pF	2.2 V
INFINEON IPG20N06S2L65AUMA1
INFINEON IPG20N04S4L08ATMA1	Surface Mount	AEC-Q101	2	N-Channel	Dual	20 A	Automotive	Logic Level Gate	PG-TDSON-8-4	54 W	8-PowerVDFN	8.2 mOhm	40 V	39 nC	-55 °C	175 °C	MOSFET (Metal Oxide)	3050 pF	2.2 V
INFINEON IPG20N10S436AATMA1	Surface Mount Wettable Flank	AEC-Q101	2	N-Channel	Dual	20 A	Automotive		PG-TDSON-8-10	43 VA	8-PowerVDFN	36 mOhm	100 V	15 nC	-55 °C	175 °C	MOSFET (Metal Oxide)	990 pF	3.5 V
INFINEON IPG20N04S4L08AATMA1	Surface Mount Wettable Flank	AEC-Q101	2	N-Channel	Dual	20 A	Automotive	Logic Level Gate	PG-TDSON-8-10	54 W	8-PowerVDFN	8.2 mOhm	40 V	39 nC	-55 °C	175 °C	MOSFET (Metal Oxide)	3050 pF	2.2 V
INFINEON IPG20N04S412AATMA1	Surface Mount Wettable Flank	AEC-Q101	2	N-Channel	Dual	20 A	Automotive		PG-TDSON-8-10	41 W	8-PowerVDFN	12.2 mOhm	40 V	18 nC	-55 °C	175 °C	MOSFET (Metal Oxide)	1470 pF	4 V
INFINEON IPG20N04S408ATMA1	Surface Mount		2	N-Channel	Dual	20 A			PG-TDSON-8-4	65 VA	8-PowerVDFN	7.6 mOhm	40 V	36 nC	-55 °C	175 °C	MOSFET (Metal Oxide)	2940 pF	4 V

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

IPG20N06S2L50AATMA1 | Datasheet
