F881KF102K300C

Active

KEMET

CAP FILM 1000PF 10% 1KVDC RADIAL

Search across all available documentation for this part.

Active

KEMET

CAP FILM 1000PF 10% 1KVDC RADIAL

Technical Specifications

Parameters and characteristics for this part

Specification	F881KF102K300C

Applications	EMI, RFI Suppression
Capacitance	0.001 µF
Dielectric Material	Metallized, Polypropylene (PP)
Height - Seated (Max) [Max]	0.354 in
Height - Seated (Max) [Max]	9 mm
Lead Spacing	0.394 in
Lead Spacing	10 mm
Mounting Type	Through Hole
Operating Temperature [Max]	110 °C
Operating Temperature [Min]	-40 °C
Package / Case	Radial
Size / Dimension [x]	13 mm
Size / Dimension [x]	0.512 in
Size / Dimension [y]	4 mm
Size / Dimension [y]	0.157 in
Termination	PC Pins
Tolerance	10 %
Voltage Rating - AC	300 V
Voltage Rating - DC	1 kVDC
Voltage Rating - DC	1 kV

Part	Operating Temperature [Min]	Operating Temperature [Max]	Lead Spacing	Lead Spacing	Capacitance	Voltage Rating - AC	Package / Case	Tolerance	Mounting Type	Dielectric Material	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Applications	Termination	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Voltage Rating - DC	Voltage Rating - DC
KEMET F881KF102K300C	-40 °C	110 °C	0.394 in	10 mm	0.001 µF	300 V	Radial	10 %	Through Hole	Metallized Polypropylene (PP)	4 mm	13 mm	0.157 in	0.512 in	EMI RFI Suppression	PC Pins	0.354 in	9 mm	1 kVDC	1 kV

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

1000 pF Film Capacitor 300V 1000V (1kV) Polypropylene (PP), Metallized Radial
