NMUSB202MC-R7
ObsoleteMurata Electronics
DGTL ISOL 3000VAC 2CH USB MODULE
NMUSB202MC-R7
ObsoleteMurata Electronics
DGTL ISOL 3000VAC 2CH USB MODULE
Description
General part information
NMUSB Series
USB Digital Isolator 3000VAC 2 Channel 12Mbps CMTI 13-SMD Module
Technical Specifications
Parameters and characteristics for this part
| Specification | NMUSB202MC-R7 |
|---|---|
| Channel Type | Bidirectional |
| Data Rate | 12 Mbps |
| Inputs - Side 1 | 1 |
| Inputs - Side 2 | 1 |
| Isolated Power | Yes |
| Mounting Type | Surface Mount |
| Number of Channels | 2 |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | 13-SMD Module |
| Package Name | Module |
| Technology | Magnetic Coupling |
| Type | USB |
| Voltage - Isolation | 3 kV |
| Voltage - Supply (Maximum) | 5.5 V |
| Voltage - Supply (Minimum) | 4.5 V |
