AXT622124

Obsolete

Panasonic Electric Works

CONN HDR 22POS SMD GOLD

Search across all available documentation for this part.

Obsolete

Panasonic Electric Works

CONN HDR 22POS SMD GOLD

Technical Specifications

Parameters and characteristics for this part

Specification	AXT622124

Connector Type	Header, Center Strip Contacts
Contact Finish	Gold
Features	Solder Retention
Height Above Board [z]	0.84 mm
Height Above Board [z]	0.033 "
Mated Stacking Heights	1 mm
Mounting Type	Surface Mount
Number of Positions	22 positions
Number of Rows	2
Pitch [x]	0.016 in
Pitch [x]	0.4 mm

Part	Contact Finish	Pitch [x]	Pitch [x]	Connector Type	Features	Height Above Board [z]	Height Above Board [z]	Mated Stacking Heights	Number of Rows	Number of Positions	Mounting Type
Panasonic Electric Works AXT622124	Gold	0.016 in	0.4 mm	Header Center Strip Contacts	Solder Retention	0.84 mm	0.033 "	1 mm	2	22 positions	Surface Mount

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

22 Position Connector Header, Center Strip Contacts Surface Mount Gold
