SRE6603-6R8M

Obsolete

Bourns Inc.

FIXED IND 6.8UH 1.2A 65 MOHM SMD

Search across all available documentation for this part.

Obsolete

Bourns Inc.

FIXED IND 6.8UH 1.2A 65 MOHM SMD

Technical Specifications

Parameters and characteristics for this part

Part	Current Rating (Amps)	Package / Case	Inductance	Current - Saturation (Isat)	Frequency - Self Resonant	Inductance Frequency - Test	Material - Core	DC Resistance (DCR)	Mounting Type	Shielding	Operating Temperature [Min]	Operating Temperature [Max]	Q @ Freq	Type	Tolerance	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	DC Resistance (DCR) [Max]
Bourns Inc. SRE6603-152M	120 mA	Nonstandard	1.5 mH	35 mA	2 MHz	100 kHz	Ferrite	4.2 Ohm	Surface Mount	Shielded	-25 °C	105 ░C	50 100 kHz	Drum Core Wirewound	20 %	4.45 mm	0.175 in	6.6 mm	0.26 in
Bourns Inc. SRE6603-2R2M	1.8 A	Nonstandard	2.2 µH	920 mA	120 MHz	100 kHz	Ferrite	50 mOhm	Surface Mount	Shielded	-25 °C	105 ░C	40 200 kHz	Drum Core Wirewound	20 %	4.45 mm	0.175 in	6.6 mm	0.26 in
Bourns Inc. SRE6603-6R8M	1.2 A	Nonstandard	6.8 µH	580 mA	50 MHz	100 kHz	Ferrite		Surface Mount	Shielded	-25 °C	105 ░C	40 200 kHz	Drum Core Wirewound	20 %	4.45 mm	0.175 in	6.6 mm	0.26 in	65 mOhm
Bourns Inc. SRE6603-222M	100 mA	Nonstandard	2.2 mH	28 mA	2 MHz	100 kHz	Ferrite		Surface Mount	Shielded	-25 °C	105 ░C	50 100 kHz	Drum Core Wirewound	20 %	4.45 mm	0.175 in	6.6 mm	0.26 in	8.5 Ohm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

6.8 µH Shielded Drum Core, Wirewound Inductor 1.2 A 65mOhm Max Nonstandard
