1-2299959-1
ActiveTE Connectivity AMP Connectors
THERMOCOUPLE CONNECTOR, RECEPTACLE, K TYPE, 2 POSITION
1-2299959-1
ActiveTE Connectivity AMP Connectors
THERMOCOUPLE CONNECTOR, RECEPTACLE, K TYPE, 2 POSITION
Description
General part information
Dynamic Series Thermocouple Connector Series
Headers & Wire Housings THERMOCOUPLE CONN KTYPE TAB Free Hngng
Technical Specifications
Parameters and characteristics for this part
| Specification | 1-2299959-1 |
|---|---|
| Cable Termination | Spring Clamp |
| Connector Type | Receptacle |
| Contact Type | Female Socket |
| Fastening Type | Latch Lock |
| Mounting Type | Free Hanging (In-Line) |
| Number of Positions | 2 |
| Number of Rows | 1 |
| Pitch | 0.098 in |
| Wire Gauge (AWG) (Max) | 32 AWG |
| Wire Gauge (AWG) (Min) | 19.5 AWG |
| Wire Type | Discrete |
