Description
General part information
1SNL Series
1 Pole, 80 A Current Rating (UL), 7 Position, DIN Rail, -55 – 110 °C [-67 – 230 °F], Power Distribution Blocks
Technical Specifications
Parameters and characteristics for this part
| Specification | 1SNL308010R0000 |
|---|---|
| Current Rating | 80 A |
| Line Side Connection Type | Screw Connection |
| Line Side Connections Per Pole | 1 |
| Load Side Connection Type | Screw Connection |
| Load Side Connections Per Pole | 6 |
| Number of Poles | 1 |
| Type | Power Distribution Block |
| Voltage - Rated | 1000 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
1SNL308010R0000 | Datasheet
EU_Declaration_of_Conformity
Entrelec Compact Power Block
ENTRELEC DBL Power Distribution Blocks Catalogue
ENTRELEC Compact Power Block
ENTRELEC Terminal Blocks Catalogue (RUS)
Essential Entrelec Terminal Blocks
C E R T I F I C A T E O F C O M P L I A N C E TERMINAL BLOCKS
DBL80
DBL Power-Distribution-Blocks
Datasheet
ENTRELEC Terminal Block - Master Catalog
CoC-161378-70041177-80024380-DBL
