MICRO-FIT+ VERSA COLOR FEMALE-TO-MICRO-FIT+ VERSA COLOR FEMALE OFF-THE-SHELF (OTS) CABLE ASSEMBLY, DUAL ROW, 600.00MM LENGTH, TIN (SN) PLATING, 16 AWG, 4 CIRCUITS, NATURAL (WHITE)

Find alt

Alpha

2261992044

Active

Molex

MICRO-FIT+ VERSA COLOR FEMALE-TO-MICRO-FIT+ VERSA COLOR FEMALE OFF-THE-SHELF (OTS) CABLE ASSEMBLY, DUAL ROW, 600.00MM LENGTH, TIN (SN) PLATING, 16 AWG, 4 CIRCUITS, NATURAL (WHITE)

Find alt

Alpha

Description Specifications Series Pricing CAD Documents

Description

General part information

226199 Series

Micro-Fit+ Versa Color Female-to-Micro-Fit+ Versa Color Female Off-the-Shelf (OTS) Cable Assembly, Dual Row, 150.00mm Length, Tin (Sn) Plating, 16 AWG, 4 Circuits, Natural (White)

Technical Specifications

Parameters and characteristics for this part

Specification	2261992044

Cable Termination	Crimp
Color	Black, Individual
Connector Type	Socket to Socket
Contact Finish	Tin
Contact Finish Thickness	98.4 µin
Length	1.97 ft
Number of Positions	4
Number of Rows	2
Pitch - Connector	0.118 in
Shielding	Unshielded

226199 Series

Micro-Fit+ Versa Color Female-to-Micro-Fit+ Versa Color Female Off-the-Shelf (OTS) Cable Assembly, Dual Row, 150.00mm Length, Tin (Sn) Plating, 16 AWG, 4 Circuits, Natural (White)

Part	Shielding	Connector Type	Number of Rows	Length	Pitch - Connector	Cable Termination	Number of Positions	Contact Finish Thickness	Contact Finish	Color
Molex 2261991043	Unshielded	Socket to Socket	2	0.984 ft	0.118 in	Crimp	4	98.4 µin	Tin	Black Individual
Molex 2261991082	Unshielded	Socket to Socket	2	0.492 ft	0.118 in	Crimp	8	98.4 µin	Tin	Black Individual
Molex 2261992064	Unshielded	Socket to Socket	2	1.97 ft	0.118 in	Crimp	6	98.4 µin	Tin	Black Individual
Molex 2261992084	Unshielded	Socket to Socket	2	1.97 ft	0.118 in	Crimp	8	98.4 µin	Tin	Black Individual
Molex 2261991022	Unshielded	Socket to Socket	1	0.492 ft	0.118 in	Crimp	2	98.4 µin	Tin	Black Individual
Molex 2261991084	Unshielded	Socket to Socket	2	1.97 ft	0.118 in	Crimp	8	98.4 µin	Tin	Black Individual
Molex 2261991062	Unshielded	Socket to Socket	2	0.492 ft	0.118 in	Crimp	6	98.4 µin	Tin	Black Individual
Molex 2261992042	Unshielded	Socket to Socket	2	0.492 ft	0.118 in	Crimp	4	98.4 µin	Tin	Black Individual
Molex 2261992063	Unshielded	Socket to Socket	2	0.984 ft	0.118 in	Crimp	6	98.4 µin	Tin	Black Individual
Molex 2261992044	Unshielded	Socket to Socket	2	1.97 ft	0.118 in	Crimp	4	98.4 µin	Tin	Black Individual

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

Drawing

2261992044 | Datasheet
