Specification	ATP04-2P-PM08G

Color	Black
Connector Type	Receptacle
Contact Termination	Crimp
Contact Type	Male Pin
Fastening Type	Latch Holder
Features	Sealed
Insulation Material	Thermoplastic
Mounting Type	Panel Mount
Note	Contacts Not Included
Number of Positions	2
Number of Rows	1
Operating Temperature (Max)	125 °C
Operating Temperature (Min)	-55 °C

ATP04-2P Series

Part	Mounting Type	Connector Type	Operating Temperature (Max)	Operating Temperature (Min)	Number of Positions	Insulation Material	Features	Contact Type	Contact Termination	Color	Fastening Type	Number of Rows	Contact Finish - Post	Ingress Protection Description	Ingress Protection IP Rating	Contact Finish - Mating	Contact Material	Termination	Pitch - Mating	Number of Positions Loaded	Insulation Height	Current Rating	Contact Length - Post	Insulation Color	Contact Shape	Style	Shrouding	Note
McGill Microwave Systems ATP04-2P-SR01BK	Free Hanging (In-Line)	Receptacle	125 °C	-55 °C	2	Thermoplastic	Cap (Cover) IP68 IP69K Sealed Strain Relief	Male Pin	Crimp	Black	Latch Holder	1
McGill Microwave Systems ATP04-2P-MM01	Free Hanging (In-Line)	Receptacle	125 °C	-55 °C	2	Thermoplastic	Cap (Cover) IP68 IP69K Reduced Wire Seals	Male Pin	Crimp	Gray	Latch Holder	1
McGill Microwave Systems ATP04-2P-BM03	Through Hole	Receptacle	125 °C	-55 °C	2	Thermoplastic	Board Guide Board Lock Sealed	Male Pin			Latch Holder	1	Tin	Dust Tight Water Resistant Waterproof	IP68 IP69K	Tin	Copper Alloy	Solder	0.264 in	All	1.126 in	25 A	0.146 in	Black	Circular	Board Cable/Wire	Shrouded - 4 Wall
McGill Microwave Systems ATP04-2P-MM01BLK	Free Hanging (In-Line)	Receptacle	125 °C	-55 °C	2	Thermoplastic	Cap (Cover) IP68 IP69K Reduced Wire Seals	Male Pin	Crimp	Black	Latch Holder	1
McGill Microwave Systems ATP04-2P-EC01	Free Hanging (In-Line)	Receptacle	125 °C	-55 °C	2	Thermoplastic	Cap (Cover) Sealed	Male Pin	Crimp	Gray	Latch Holder	1																Contacts Not Included
McGill Microwave Systems ATP04-2P-PM08GEC	Panel Mount	Receptacle	125 °C	-55 °C	2	Thermoplastic	Cap (Cover) Sealed	Male Pin	Crimp	Black	Latch Holder	1																Contacts Not Included
McGill Microwave Systems ATP04-2P-PM07GEC	Panel Mount	Receptacle	125 °C	-55 °C	2	Thermoplastic	Cap (Cover) Sealed	Male Pin	Crimp	Black	Latch Holder	1																Contacts Not Included
McGill Microwave Systems ATP04-2P-SR01	Free Hanging (In-Line)	Receptacle	125 °C	-55 °C	2	Thermoplastic	Cap (Cover) IP68 IP69K Sealed Strain Relief	Male Pin	Crimp	Gray	Latch Holder	1
McGill Microwave Systems ATP04-2P-BM12	Through Hole	Receptacle	125 °C	-55 °C	2	Thermoplastic	Board Guide Potting Wall Sealed	Male Pin			Latch Holder	1	Gold	Dust Tight Water Resistant Waterproof	IP68 IP69K	Gold	Copper Alloy	Solder	0.264 in	All	1.126 in	25 A	0.146 in	Black	Circular	Board Cable/Wire	Shrouded - 4 Wall
McGill Microwave Systems ATP04-2P-BLK	Free Hanging (In-Line)	Receptacle	125 °C	-55 °C	2	Thermoplastic	Sealed	Male Pin	Crimp	Black	Latch Holder	1																Contacts Not Included
